Sony ss dp 800 avw service manual
This is the 4 pages manual for sony ss dp 800 avw service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss dp 800 avw service manual (Ocr-read)
Page 1
2 Ref. No. Part No. Description Remark ––––––– ––––––– ––––––––– –––––– EXPLODED VIEW AND PARTS LIST NOTE:- Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - The mechanical parts with no reference num- ber in the exploded views are not supplied. SS-DP700/DP800AVW/DP1000DW 12 3 3 4 4 45 7 6 not supplied not supplied SP1 SP2 8 1 A-4412-746-A FRAME ASSY, GRILLE 2 A-4412-747-A PANEL ASSY, FRONT *3 4-963-075-01 CATCHER 4 4-874-614-21 SCREW (4) (3.5X14), TAPPING 5 A-4412-748-A CABINET ASSY, SPEAKER 6 1-537-332-11 TERMINAL BOARD 7 1-757-627-11 CORD (WITH C) 8 4-232-728-01 PACKING SP-1 1-529-985-11 SPEAKER (16CM) SP-2 1-529-984-11 SPEAKER (5CM)Ref. No. Part No. Description Remark ––––––– ––––––– ––––––––– –––––– ACCESSORIES & PACKING MATERIALS ******************************* 1-558-848-11 CORD, SPEAKER (2.5M) 4-232-734-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH, GERMAN, SPANISH, DUTCH, SWEDISH, ITALIAN, PORTUGUESE, TURKISH, POLISH, HUNGARIAN, GREEK, FINNISH, DANISH, CZECH) (DP700, DP800AVW, DP1000DW:AEP)
Page 2
3 SS-DP700/DP800AVW/DP1000DW MEMO
