Page 2
SS-D205
3. EXPLODED VIEW AND PARTS LIST
NOTE:
. Items marked V are not stocked
since they are seldom required for
routine service, Some deiav should be
anticipated when ordering these items.
0 The mechanical parts with no reference
number in xhe exploded views are not
supplied.
Reero. Part No. Description
1 X-4941-372-1 PAENL (L) ASSV. FRONT
1 X-4941-373-1 PAENL (R) ASSV. ROM
2 1575-697-11 CORD. SPEAKER (WITH (6))
3 X-4941-383-1 CABINET (L) ASSY. SPEAKER
3 X-4941-384-I CABINET (R) ASSY. SPEAKER
4 4-874-614-61 SCREW (M3. 5X16)
9-956-420-11
Remark Ref No. Part No. Description
SP1 1-544-451-11 SPEAKER (1661)
SP2 1-544-454-I1 SPEAKER ($0M)
8P3 1-544-454~11 SPEAKER ($6M)
ACCESSORY & PACKING MATERIAL
*Hfififinfl*HHHflHfiH
4-944-58401 CUSHION
Sony Corporation
Audio Group
English
91D0214-1
Printed in Japan
©1991.4
Published by Customer Relations and Service Group
__2_
