2 SS-CTLF1 EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied.--XX, -X mean standardized parts, so they may have some differences from the original one. 1X-2024-143-1 FRAME (CENTER) ASSY, GRILLE 24-229-966-12 SCREW (4X16), +BV TAPPING 34-986-971-12 SCREW (3.5) 42-102-640-01 COVER 52-102-634-01 BODY (CENTER), ALUMINUM 62-149-009-01 FOOT (C- STAND) 72-149-011-01 STAND, CENTER SP Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 81-829-423-11 CORD (WITH CONNECTOR) 92-350-305-01 SCREW SP1 1-825-964-11 SPEAKER (10cm) SP2 X-2023-106-1 TWEETER ASSY (2.5cm) #1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S #2 7-685-872-09 SCREW +BVTT 3X8 (S) #3 7-685-651-79 SCREW +BVTP 3X20 TYPE2 N-S a a 22 134 4 5 not supplied not suppliedSP1 SP2 not supplied not supplied 9 #1#2 #2 7 68 #3
Page 2
3 SS-CTLF1 MEMO
