Sony ss ct 43 service manual
This is the 4 pages manual for sony ss ct 43 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss ct 43 service manual (Ocr-read)
Page 1
2 SS-CT43/GS21/TS43/TS43B EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied.-XX and -X mean standardized parts, so they may have some difference from the original one. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1X-2055-023-1 ASSY, GRILLE FRAME (PUNCHING) 24-874-614-81 +BVTP 3.5X16 TYPE2 32-048-751-01 SCREW +BVTP 3.5X14 TYPE2 44-255-545-01 FOOT5A-1107-337-A OVERALL ASSY 61-694-836-11 TERMINAL, SPEAKER 1 2 2 2 3 4 not suppliednot supplied not supplied 5 6 SS-CT43
Page 2
3 SS-CT43/GS21/TS43/TS43B SS-TS43 SS-TS43B Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 5152 5255 53 54 54 54 SP1not supplied not supplied not supplied 51 X-2055-022-1 ASSY, GRILLE FRAME (PUNCHING) 52 4-874-614-81 +BVTP 3.5X16 TYPE2 53 2-048-751-01 SCREW +BVTP 3.5X14 TYPE2 54 4-255-545-01 FOOT 55 A-1107-336-A OVERALL ASSY (TS43)55 A-1107-338-A OVERALL ASSY (TS43B) SP1 1-826-185-11 SPEAKER (7X10cm) (TS43) SP1 1-826-188-11 SPEAKER (7X10cm) (TS43B)
