Sony ss cnx 70 ed service manual
This is the 4 pages manual for sony ss cnx 70 ed service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss cnx 70 ed service manual (Ocr-read)
Page 1
2 SS-CNX70ED NOTE: - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - Hardware (# mark) list and accessories and pack- ing materials are given in the last of this parts list. Ref. No. Part No. Description Remark EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark SP2#1 not supplied SP1 3 3 2 24 4 1 876 5 1 X-4954-949-1 FRAME ASSY, GRILLE...(WOOD) 1 X-4954-954-1 FRAME ASSY, GRILLE...(BLACK) 2 4-235-904-01 SCREW, HEXAGON SOCKET TP 4X25 3 4-241-438-01 RING, ORNAMENTAL 4 4-210-830-01 CATCHER 5 X-4954-901-1 COVER ASSY, TW...(BLACK) 5 X-4954-910-1 COVER ASSY (M), TW...(WOOD) 6 4-874-614-11 SCREW +BVTP 3.5X14 7 1-694-029-11 TERMINAL BOARD (SP) 8 4-949-384-11 EMBLEM (No.6), SONY SP1 1-825-147-11 SPEAKER (12cm) SP2 1-825-147-11 SPEAKER (12cm) #1 7-683-420-04 BOLT, HEXAGON SOCKET 4X10 ****************************************************** ACCESSORIES *********** 4-240-887-11 MANUAL,INSTRUCTION (ENGLISH,FRENCH,SPANISH,PORTUGUESE, TRADITIONAL CHINESE,SIMPLIFIED CHINESE) 4-972-322-01 FOOT (Y)
Page 2
3 SS-CNX70ED MEMO
