Sony ss cnp 760 service manual

This is the 4 pages manual for sony ss cnp 760 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 4
sony ss cnp 760 service manual

Extracted text from sony ss cnp 760 service manual (Ocr-read)


Page 1

2 SS-CNP760/CRP760/MSP760L/MSP760R/MSP760SL/MSP760SREXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied. Ref. No. Part No. Description Remark 1 A-4713-761-A OVERALL ASSY 2 1-694-516-11 TERMINAL, SPEAKER 3 4-246-231-01 SCREW (3.5X14) 4 4-986-971-02 SCREW (3.5) SS-CNP760 --XX and -X mean standardized parts, so they may have some difference from the original one. 4 2 3 1 3 not supplied not supplied not supplied not supplied not supplied

Page 2

3 SS-CNP760/CRP760/MSP760L/MSP760R/MSP760SL/MSP760SR Ref. No. Part No. Description Remark 1 A-4713-765-A OVERALL ASSY 2 1-694-516-11 TERMINAL, SPEAKER 3 4-246-231-01 SCREW (3.5X14) 4 4-986-971-02 SCREW (3.5) SS-MSP760L/MSP760R/MSP760SL/MSP760SR 4 3 2 3 not supplied not supplied not supplied not supplied not supplied 1
