Sony ss cnp 76 service manual
This is the 6 pages manual for sony ss cnp 76 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss cnp 76 service manual (Ocr-read)
Page 1
SS-CNP76/CRP76/MSP76/VE81P/WMSP81 2 1A-4723-985-A FRONT PANEL ASSY 24-986-971-01 SCREW (3.5) 34-243-839-01 CABINET 44-229-803-11 PACKING Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51-694-516-11 TERMINAL, SPEAKER 64-246-231-01 SCREW (3.5X14) SP1 1-825-003-12 SPEAKER (7X10cm) 1 3 2 6 4 5 6 SP1not supplied SS-CNP76 EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied.--XX, -X mean standardized parts, so they may have some differences from the original one.
Page 2
3 SS-CNP76/CRP76/MSP76/VE81P/WMSP81 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark SS-MSP76 1 2 3 6 5 6 4 not supplied SP2 1A-4723-981-A FRONT PANEL ASSY 24-986-971-01 SCREW (3.5) 3A-4723-982-A CABINET ASSY 44-229-803-11 PACKING51-694-516-11 TERMINAL, SPEAKER 64-246-231-01 SCREW (3.5X14) SP2 1-825-003-12 SPEAKER (7X10cm)
