2 SS-CNP700/MSP700/SRP700/WP700 SS-CNP700/MSP700/SRP700 EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied.--XX, -X mean standardized parts, so they may have some differences from the original one. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1A-1154-979-A OVERALL ASSY (SS-MSP700) 1A-1154-983-A OVERALL ASSY (SS-SRP700)2A-1154-981-A OVERALL ASSY (SS-CNP700) 1 2

Page 2

3 SS-CNP700/MSP700/SRP700/WP700 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 51 A-1156-547-A FRONT PANEL ASSY 52 1-826-423-11 LOUD SPEAKER (20cm)53 4-245-976-01 SCREW (4X16) (TYPE 1), +BVTP SS-WP700 5153 52 not supplied
