2 SS-CNP680/CNP900/MSP880/MSP900/SRP880/SRP900 SS-CNP680/MSP900/SRP900 EXPLODED VIEWS NOTE: -The mechanical parts with no reference number in the exploded views are not supplied. - -XX, -X mean standardized parts, so they may have some differences from the original one. - Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) R R Parts of Color Cabinets Color Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 A-1154-989-A OVERALL ASSY (SILVER)(SS-CNP680) (E51) 1 A-1159-489-A OVERALL ASSY (SILVER)(SS-MSP900) (CND, US) 1 A-1159-490-A OVERALL ASSY (SILVER)(SS-SRP900) (CND, US) 1 A-1159-532-A OVERALL ASSY (SILVER)(SS-CNP680) (CND, US)1 A-1182-562-A OVERALL ASSY (BLACK)(SS-MSP900) (US) 1 A-1182-563-A OVERALL ASSY (BLACK)(SS-CNP680) (US) 1 A-1182-566-A OVERALL ASSY (BLACK)(SS-SRP900) (US) 1 A-1183-337-A OVERALL ASSY (SILVER)(SS-CNP680) (AEP, UK, RU, SP, SP6 ,AUS) 1 -Abbreviation AU S: A ustralian model CND : Canadian model E51 : Chilean and Peruvian models RU : Russian model SP : Singapore model SP6 : Singapore and Malaysia models Ve r. 1.1
Page 2
3 SS-CNP680/CNP900/MSP880/MSP900/SRP880/SRP900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark SS-CNP900/MSP880/SRP880 51 53 52 51 A-1156-026-A OVERALL ASSY (SS-MSP880)(BLACK)(E51) 51 A-1187-006-A OVERALL ASSY (SS-MSP880)(MAPLE)(AEP, UK, SP, AUS) 52 A-1156-030-A OVERALL ASSY (SS-SRP880)(BLACK)(E51) 52 A-1187-008-A OVERALL ASSY (SS-SRP880)(MAPLE) (AEP, UK, SP, AUS) 53 A-1156-028-A OVERALL ASSY (SS-CNP900)(BLACK)(E51) 53 A-1187-007-A OVERALL ASSY (SS-CNP900)(MAPLE) (AEP, UK, SP, AUS)
