2 SS-CM100 NOTE: - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - Hardware (# mark) list and accessories and pack- ing materials are given in the last of this parts list. - Abbreviation HK : Hong Kong model SP : Singapore model KR : Korea model AUS : Australian model Ref. No. Part No. Description Remark EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark R-ch 1 X-4954-180-1 FRAME (L) ASSY, GRILLE (WHITE) 1 X-4954-181-1 FRAME (R) ASSY, GRILLE (WHITE) 1 X-4954-279-1 FRAME (L) ASSY, GRILLE (BLACK) (AEP,UK) 1 X-4954-280-1 FRAME (R) ASSY, GRILLE (BLACK) (AEP,UK) 1 X-4954-281-1 FRAME (L) ASSY, GRILLE (SILVER) (AEP,UK,HK,KR) 1 X-4954-282-1 FRAME (R) ASSY, GRILLE (SILVER) (AEP,UK,HK,KR)2 4-916-118-01 SCREW (4) (3.5X20), TAPPING 3 A-4735-715-B SYSTEM ASSY (WHITE) (HK,SP,KR,AUS) 3 A-4735-717-B SYSTEM ASSY (SILVER) (HK,KR) 3 A-4746-445-A SYSTEM ASSY (BLACK) (AEP,UK) 3 A-4746-454-A SYSTEM ASSY (WHITE) (AEP,UK) 3 A-4746-881-A SYSTEM ASSY (SILVER) (AEP,UK) 1 223 2 not suppliednot suppliednot supplied
