Sony ss ccp 33 service manual
This is the 2 pages manual for sony ss ccp 33 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ss ccp 33 service manual (Ocr-read)
Page 1
2 Sony Corporation Audio Entertainment Group 9-929-277-11 2000E1672-1 Printed in Japan © 2000.5 Published by HA Quality Assurance Dept. EXPLODED VIEW AND PARTS LIST NOTE: - -XX, -X mean standardized parts, so they may have some differences from the original one. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.- The mechanical parts with no reference number in the exploded views are not supplied. Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1 X-4952-861-1 NETASSY, SPEAKER 2 4-227-276-01 WOOFER (PANEL) 3 4-874-614-11 SCREW(4) (3.5X14), TAPPING 4 4-218-202-01 CATCHER, NET 5 X-4952-860-1 BOX ASSY, SPEAKER6 4-870-003-00 CLIPPER, CODE 7 A-4412-189-A PANEL ASSY,TWEETER SP1 1-529-727-11 SPEAKER(12cm)(WOOFER) SP2 1-529-476-11 SPEAKER(2.5cm)(TWEETER) SP1SP2 1 35 7 6 4 not supplied 3 2 not supplied
