2 SS-CCP11 EXPLODED VIEW AND PARTS LIST NOTE: --XX, -X mean standardized parts, so they may have some differences from the original one. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - The mechanical parts with no reference number in the exploded views are not supplied. R-CH Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1 X-4952-727-1 NET ASSY, SPEAKER 2 4-217-353-01 PANEL(WOOFER) 3 4-874-614-11 SCREW(4) (3.5X14), TAPPING 4 4-218-202-01 CATCHER, NET 5 4-217-365-01 BOX(L), SPEAKER (L-CH) 5 4-217-366-01 BOX(R), SPEAKER (R-CH) 6 4-870-003-00 CLIPPER, CODE 7 A-4412-189-A PANEL ASSY, TWEETER SP1 1-529-727-11 SPEAKER (12cm) (WOOFER) SP1 1 3 5 7 6 4 not supplied not supplie d 3 2 Ver 1.1 2002.04
