SS-BG30 Ñ 2 Ñ Sony Corporation Home A&V Products Company 97J7554-1 Printed in Germany © 1997. 10 Published by General Engineering Dept. (Shibaura) 9-922-728-11 1. EXPLODED VIEW AND PARTS LIST Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-860-848-11 INSTRUCTION MANUAL (ENGLISH,FRENCH,SPANISH,PORTUGUESE ,GERMAN,DUTCH,ITALIAN,SWEDISH,DANISH ,FINNISH,RUSSIAN,POLISH,CZECH ,HUNGARIAN) 1 X-4948-999-1 SPEAKER CABINET ASSY 2 4-961-784-01 SCREW P 4.0 X 25 T15 3 4-997-489-01 SCREW P 3.5 X 15 T15 4 4-961-785-01 SCREW P 3.5 X 20 T15 5 1-761-012-11 MOUNTED P.C.B. 6 1-694-396-11 TERMINAL BOARD SP1 1-505-779-11 SPEAKER (1.9 cm) (TWEETER) SP2 1-505-778-11 SPEAKER (13 cm) (WOOFER) 1 4 4 56 SP1 SP2 2 2 2 3 3 not supplied not supplied not supplied not supplied
