Ñ 2 Ñ SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.ATTENTION AU COMPOSANT AYANT RAPPORT Ë LA SƒCURITƒ! LES COMPOSANTS IDENTIFƒS PAR UNE MARQUE ! SUR LES DIAGRAMMES SCHƒMATIQUES ET LA LISTE DES PIéCES SONT CRITIQUES POUR LA SƒCURITƒ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIéSES SONY DONT LES NUMƒROS SONT DONNƒS DANS CE MANUEL OU DANS LES SUPPƒMENTS PUBLIƒS PAR SONY. DIFFERENT SPECIFICATIONS MODEL SPECIFICATIONS AUDIO SYSTEM TUNER AUDIO (STEREO) SYSTEM VCR+ SYSTEM LINE 2 INPUT BODY COLOR DUAL MODE SHUTTLE REMOTE COMMANDER SLV-478 MONAURAL Ñ Ñ Ñ BLACK Ñ RMT-V231A SLV-L67HF SLV-L68HF HiFi-STEREO SAP Ñ Ñ BLACK TITAN Ñ RMT-V231 SLV-688HF HiFi-STEREO SAP BUILT-IN BUILT-IN BLACK Ñ RMT-V231B SLV-L47 SLV-L48 MONAURAL Ñ Ñ Ñ BLACK Ñ RMT-V230 SLV-L57 SLV-L58 MONAURAL Ñ Ñ BUILT-IN BLACK BUILT-IN RMT-V232 MODEL SPECIFICATIONS AUDIO SYSTEM TUNER AUDIO (STEREO) SYSTEM VCR+ SYSTEM LINE 2 INPUT BODY COLOR DUAL MODE SHUTTLE REMOTE COMMANDER SLV-677HF SLV-678HF HiFi-STEREO SAP Ñ Ñ TITAN BLACK Ñ RMT-V231A SLV-L77HF SLV-L78HF HiFi-STEREO SAP Ñ BUILT-IN BLACK TITAN BUILT-IN RMT-V232 SLV-X50 MONAURAL Ñ Ñ Ñ TITAN BUILT-IN RMT-V232 SLV-X60HF HiFi-STEREO SAP Ñ Ñ TITAN Ñ RMT-V231
