SEIl-III

SERVICE MANUAL

US Model
Canadian Model
AEP Model

SPECIFICATIONS

Inputs LINE IN: Phonojaoks. 245 mV
(-10 st), SO kiiohrns
TAPE IN: Phono jacks, 245 mV
(-10 st) 50 kiIohms
Outputs LINE OUT: Phono jacks, 245 mV
(710 st),
Load impedance: more than to
kIIOIImS
TAPE REC OUT: Phono jacks, 245 mV
{-10 st),
Load impedance: more than 10
kiIohms
Graphic equalizer Boost/cut range, t 10 dB
Center irequencie : 63 Hz, 160 Hz,
400 HZ, 1 kHz, 2.5 kHz, 6.3 kHZ,
16 kHz
Frequency response (with EFFECT OFF)
LINE IN: 20 Hz to 50 kHz, j?5dB
Harmonic distortion LINE IN: Less than 001 %
(at 1 kHz, 1 V output)
SignaHonotse ratio (wnh EFFECT OFF)
LINE IN: Better than 100 dB
(A network, 1 V output)
Power requirements 120 V AC. 60 Hz
Power consumption 13W
AC outlet 1. unswitched. 120 W/1A
Dimensions Approx.430 X 95 X 265mm (w/hld)
(17 x 3 3/5 x 1O /2 inches)
inciuding projecting parts and controls
Weight Approx: 32 kg (7 lb 1 oz)
Accessories supplied
Audio connecting cords (2)
Remote commander RM-J711(1)
Sony batteries SUMAS (NS) (2)

Dessgn and specifications are subject to change without

SAFETY-RELATED COMPONENT WARNINGII

COMPONENTS IDENTIFIED BV MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB,
LISHED BY SONY.

ATTENTION AU COMPOSANT AVANT RAPPORT
A LA SECURITEI

LES COMPOSANTS IDENTIFIES PAR UNE MAROUE A
sun LES DIAGRAMMES SCHéMATIoues ET LA LISTE
DES PIECES soNT cmTIoUES POUR LA sécURITé
DE FONCTIONNEMENTI NE REMPLACER ces com-
POSANTS oue PAR DES PIECES SONY DONT LES
NUMéRos SONT DONNés DANS CE MANUEL ou
DANS LES SUPPLEMENTS Puaués PAR some

GRAPHIC ElllIALIZER
SONY;
