SA-VE130NE150
SERVICE NAN'UAL
- SA-VE130 and VE150 are composed of models below.
As for the service manual, it is issued for each component
model, then, please refer to it.
COMPONENTS MODEL
SA-VE130 SA-VE150
SU PER WOOFE R SYSTEM SA~W303 SA-W305
CENTER SPEAKER SYSTEM SS-CN1 30 SS-CN150
REAR SPEAKER SYSTEM SS-V130 SS-V150
SPECIFICATIONS
Speaker system
SS-CNl50/CN130:
SS-VlSO/Vl30:
Speaker unit
5cm x90rn (2x35/r inches,CONE TYPE)
Enclosure iype
Buss reflex
Rated impedance
8 ohms
Power handling capacity
SS-CNISO/CN130:
SS-VlSO/VISO:
Sensitivity
SS
Frequency range
90-20,000 Hz
Dimensions
SS~CN150ICN1301
Full range x 2, magnectically shielded
Full range, magneclically shielded
Maximum input power: 120 W
Maximum input power: 100 W
BSdB (I W, 1m)
86d}; (1 W, 1m)
Approx. 301x68x134mm
(l17/3xZ3/4x53/sinches)(w/h/d)
including front grille
SS-VlSO/V I 30: Approx.67x15lxl33mm
(21/4 x6 x5 '/4 inches)(w/h/d)
including from grille
Mass
SSvCNISO: Apprpxrl.2kg(21h II) 02)
SS-VlSO: ApprpxfiflOg/pcfl lb 6 oz)
SS-CN130: Apprpx. lkg(2 lb 3 oz)
SSVV130: Apprpxr540g/pcil lb 3 oz)
Supplied accessories
Speaker cordsiGray)
SS-CN 150/CN130: 2.5m( l)
SSAVISO/VIBO: 2.5m(2)(for from speakers)
10m(2)(for rear speakers)
Feet(4)
*As for the specifications of the SA-W305/W303,see the instruction manual
supplied with [he SA-W3Il5/W303.
Design and specifications are subject to change wiLhout notice.
MICROFILM
Sony Corporation
Home A&V Products Company
9-922-844-1 1
US Model
SA-VE130/VE150
Canadian Model
AEP Model
UK Model
E model
Australian model
SA-VE 150
PARTS LIST
NOTE:
. Items marked * are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items,
Ref, No. Pan No. Description Remark
ACCESSORIES & PACKING MATERIALS
assmusMMHHMHMHWM
1-569-008-11 ADAPTOR. CONVERSION 2P (VE150:E,MY,SP)
1-751-598-11 CORD. CONNECTION (PIN-PIN)
1-769-433-11 CORD, SPEAKER
3-862-214-11 MANUAL, INSTRUCTION (ENGLISH)
(VE130NE150:US,CND.AEP,G.UK)
3-862-214-21 MANUAL, INSTRUCTION (FRENCH/ENGLISH)
(VE150:AEP,G,E,MY,SP,AUS)
3-352-214-31 MANUAL, INSTRUCTION
(SPANiSH/PORTUGUESE/GERMAN/DUTCH/
ITALIAN/SWEDiSH/DANISH/FlNNISH/
CHINESE)(VE150:E,MY,SP)
3-352-357-11 MANUAL, INSTRUCTlON
(FRENCH/ENGLIsH/SPANISH/PORTUGUESE/
GERMAN/DUTCH/ITALIAN/SWEDISH/
DANISH/FINNISH/CHINESE)
4-972-322-01 FOOT (Y)
SPEAKER SYSTEM
