Sony sava 10 service manual

This is the 22 pages manual for sony sava 10 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 22
sony sava 10 service manual

Extracted text from sony sava 10 service manual (Ocr-read)


Page 1

Ñ 2 ÑTABLE OF CONTENTS 1. GENERAL.................................................................... 4 2. DISASSEMBLY 2-1. Amplifier Assembly ............................................................. 5 3. DIAGRAMS 3-1. IC Pin Function ¥ IC501 System Control (µPD78042FGF-016-3B9) ........... 6 3-2. Circuit Boards Location ....................................................... 7 3-3. Schematic Diagram .............................................................. 9 3-4. Printed Wiring Board .......................................................... 13 3-5. IC Block Diagrams ............................................................. 17 4. EXPLODED VIEWS 4-1. Cabinet (L) Assembly ......................................................... 19 4-2. Cabinet (R) Assembly ........................................................ 20 4-3. Amplifier Section ............................................................... 21 4-4. Rear Speaker Section (SS-SR151) ..................................... 22 5. ELECTRICAL PARTS LIST .................................. 23 SERVICE NOTE [FL ALL LIGHT UP MODE] While pressing the MASTER VOL+ button, press the POWER button. [AUTO POWER SAVE MECHANISM] A part circuit on this will stop to economize in power if it has no signal after more than three minutes. If a sound is input again, the normal circuit will operated.

Page 2
