Sony ptv 5 service manual

Page 1

Power requirements

Power consu mption
Timer display

Timer setting

Clock

For, Service Manuals Cdntaci
MAURITRON TECHNICAL SERVIC
8 Cherry Tree Rd Chinnor.

Y

SPECIFICATIONS

US, Canadian model: 120V ac, 60Hz

AEP model: 220V ac, 50H2

UK model: 240V ac, 50Hz

E model: 110-120 or 220-240V ac
adjustable, 50 or 60Hz adjusiable

SW

12 hour system (US, Canadian model)

24 hour system (AEP, UK, E model)

Up to four on/ofi operations with an

accuracy measured in minuies.

Synchronized with power line frequency

Power backup duration 60 minutes (when the batteries have been

AC outlets

Dimensions

MICROFILM

charged at least 60 hours)
US, Canadian model: one switched, one
unswitched total 900W
AEP model: one swiiched, one unswitched
total 500W
UK model: two switched, total 500W
E model: one switched, one unswitched
total 400W
AEP model: approx. 355 x 55 x 255 mm iw/h/d)
(14 x ZAx 10l/s inches)
including projecting parts and controls
US, Canadian, UK, E model:
approx. 355 x 55 x 245 mm (w/h/d)
(14 x 2% x 9% inches)
including projecting parts and controls
ApproxI 2.2kg (4 lbs 13 oz) net

US Model j
, CanadiankMode/
" AEP Model
UK Model
I E Model ,

Annie; TIMER

SAFETY-RELATED COMPONENT WARNINGI!

COMPONENTS IDENTIFIED BY SHADING AND MARK

A ON THE SCHEMATIC DIAGRAMS AND IN THE
PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY

ATTENTION AU COMPOSANT AYANT RAPPORT
A LA SECURITE!

LES COMPOSANTS IDENTIFIES PAR UNE TRAME ET
UNE MARQUE A sun LES DIAGRAMMES SCHE-
MATioUES ET LA LISTE DES PIECES SONTCRITIQUES
POUR LA SECURITE DE FONCTIONNEMENT. NE REM-
PLACER ces COMPOSANTS QUE PAR DES PIECES
SONY DONT LEs NUMEROS SONT DONNES DANS CE
MANUEL ou DANS LES SUPPLEMENTS PUBLIES PAR
SONY,

N E
SERVICE MANUAL

Page 2

PT-V 5

SAFETY CHECK-OUT (US Model)

After correcting the original service problem,
perform the following safety check before releasing
the set to the customer: >
Check the antenna terminals, metal trim, metallized
knobs, screws, and all other exposed metal parts for
AC leakage. Check leakage as described below,

LEAKAGE TEST

The AC leakage from any exposed metal part to
earth ground and from all exposed metal parts to any
eXposed metal part having a return to chassis, must
not exceed 0.5 mA (500 microampers). Leakage
current Can be measured by any one of three
methods.

1. A commercial leakage tester, such as the
Simpson 229 or RCA WT-540A. Follow the
manufacturers instructions to use these instru-
ments,

2. A batteryvoperated AC milliammeter. The Data
Precision 245 digital multimeter is suitable for
this job.

3. Measuring the voltage drop across a resistor by
means of a VOM or battery~operated AC volt-
meter. The limit indication is 075 V, so
analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa
SH-63Trd are examples of a passive VOM that
is suitable, Nearly all battery operated digital
multimeters that have a 2V AC range are
suitable. (See Fig. A)

To Exposed Metal
Parts on Set

AC

0.15uF 1.5km voltmeter
(0. 75 V)

ii: Earth Ground

Fig. A. Using an AC voltmeter to check AC leakage.

MODEL IDENTIFICATION

- Specification on the Jack Plate -'

6

AUDIO TIMER
I .

®

SONYE MODEL N0.PT-V5

J

US, Canadian model: AC: 120V ~ 60Hz 3.5W
AEP model: AC: 220V ~ 50Hz 3.5W
UK model: AC: 240V ~ 50Hz 3.5W

E model: AC: 110-120V, 220-240V ~ 50/60HZ 3.5W

__2__
