Page 1
– 2 – Sony Corporation Audio Entertainment Group 2000D0451-1D Printed in Japan ©2000. 4 Published by HA Quality Assurance Dept. 9-927-150-91 52 3-042-215-01 COVER (FRONT) 55 3-025-499-01 HOLDER, CASSETTE 58 3-039-911-01 LENS, RDS 65 3-025-508-01 BUTTON (REC) 66 3-025-511-01 BUTTON (PLAY) 67 3-025-510-01 BUTTON (REW) 68 3-025-509-01 BUTTON (FF) 69 3-025-512-01 BUTTON (STOP) 70 3-025-507-01 BUTTON (PAUSE) 71 3-042-216-01 CABINET (FRONT) 72 3-039-915-01 LENS (RDS HOLDER) 74 not supplied Page INCORRECT CORRECT 41 Ref. No. Part No. Description Remark Part No. Description Remark not supplied (supplied with 71) 3-025-499- 11 HOLDER, CASSETTE not supplied (supplied with 71) 3-025-508- 11 BUTTON (REC) 3-025-511- 11 BUTTON (PLAY) 3-025-510- 11 BUTTON (REW) 3-025-509- 11 BUTTON (FF) 3-025-512-11 BUTTON (STOP) 3-025-507-11 BUTTON (PAUSE) X-3378-057-1 CABINET (FRONT) SUB ASSY not supplied 3-039-909-01 KNOB (SNOOZE) #2#2 #2 #2 #1 #1 #2 #1 #5 #5 #2 #2 #1 LCD801 not supplied D804 not suppliednot supplied not suppliedMF-107 545556 656451 74 63 62 5957 60 61 5371 66 67 68 69 70 73 ! ! # # # # # # % ^
