3 NW-MS77DR SECTION 2 GENERAL This section is extracted from instruction manual. Locating controls For details about each part, refer to the pages in parentheses. Network Walkman Rear side Front side 1 VOL (+/–) control 2 Headphone plug 3 Plug cover 4 SOUND/AVLS button 5 Memory Stick Eject button 6 Display 7 Shuttle switch 8 Play/Stop button 9 RESET button 0 USB cradle connector qa HOLD (Locking controls) switch qs MENU button You can switch to the Time display by pressing the MENU button for a while. qd Access lamp qf Memory Stick slot SECTION 1 SERVICING NOTES [ Notes on using Memory Stick Duo ] - Do not remove Memory Stick Duo during reading or writing data. - Data may be damaged in the following cases. – The Network Walkman is removed from the USB cradle or the dedicated USB cable is unpl\ ugged while reading or writing data. – The Memory Stick is used in a location subject to static electri\ city or electric noise. - Creating backup copies of important data is recommended. [ Notes on formatting (initializing) ] Memory Stick Duo is shipped with a FAT format as the standard format. To format Memory Stick, please use devices conformable with the \ Memory Stick. If Memory Stick is formatted using Windows Explorer, FORMAT ERROR will be displayed and audio files cannot be played on the Network Walkman. On Windows XP, you can format Memory Stick properly. When you format Memory Stick, always perform either one of the following: - Follow the instructions of Formatting memory. - Format using the supplied Sonic Stage software. For details on how to format using the Sonic Stage software, refer to \ Sonic Stage Online Help: Initializing an MG Memory Stick . [ Displaying on Windows Explorer ] When you connect Network Walkman to your computer with the supplied USB cable, you can display the\ data stored on Memory Stick or built-in flash memory as an external drive (for example, a\ s the D drive) using Windows Explorer. -Data transferred with the Sonic Stage software will be stored in a H\ IFI folder. Do not edit data stored in the HIFI folder using W indows Explorer. Data copied or edited using Windows Explorer cannot be played on your Network Walkman. -Y ou can display data that has been stored on other Memory Stick c\ ompatible devices (JPEG,MPEG format, etc.,). For information on how to handle data except in the HIFI folder, refer to the instruction manual that comes with the equipmen t with which the recording has been done.
