Sony nw e 8 p service manual
This is the 24 pages manual for sony nw e 8 p service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony nw e 8 p service manual (Ocr-read)
Page 1
2 NW-E8P Specifications ............................................................................... 1 1. SERVICING NOTE .......................................................... 2 2. GENERAL .......................................................................... 3 3. DISASSEMBLY 3-1. Driver ASSY (SP2), Arm Lid (R), Holder Lid (R) ......... 6 3-2. Main Board, Power Board, LCD Unit ............................ 6 3-3. Driver ASSY (SP1), Arm Lid (L), Holder Lid (L) ......... 7 4. TEST MODE ...................................................................... 8 5. DIAGRAMS 5-1. Block Diagrams ............................................................ 10 5-2. Printed Wiring Boards (Main Section) ......................... 11 5-3. Schematic Diagram (Main Section (1/2)) ..................... 12 5-4. Schematic Diagram (Main Section (2/2)) ..................... 13 5-5. Printed Wiring Boards (Power Section) ........................ 14 5-6. Schematic Diagram (Power Section) ............................ 15 6. EXPLODED VIEW 6-1. L-CH Section ................................................................ 17 6-2. R-CH Section ................................................................ 18 7. ELECTRICAL PARTS LIST ....................................... 19 Flexible Circuit Board Repairing - Keep the temperature of the soldering iron around 270°C during repairing. - Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). - Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement - Never reuse a disconnected chip component. - Notice that the minus side of a tantalum capacitor may be dam- aged by heat. TABLE OF CONTENTS - Replacement of CXD9644GG (IC710) used in the set requires a special tool. z UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead-free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK Unleaded solder has the following characteristics. - Unleaded solder melts at a temperature about 40°C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350°C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! - Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. - Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. z USABLE FORMAT Use ISO9660 Level 1 format. SECTION 1 SERVICING NOTE
Page 2
3 NW-E8P SECTION 2 GENERAL LOCATION AND FUNCTION OF CONTROLS This section is extracted from instruction manual. (front of the right player) Display 1 AVLS indication 2 MEGA BASS indication 3 Battery remain indication 4 Play mode indication 5 Text/graphic information display 1 DISPLAY button 2 VOLUME+/– button 3 HOLD switch 4 Jog lever 5 Dedicated USB jack 6 Display 7 MEGA BASS/AVLS button 8 P.MODE button 9 Ear pad 0 Battery compartment 1 2 34 56 7 8 (rear of the left player) 9 0 12 3 4 5
