Extracted text from sony nw e 503 e505 e507 portable ic audio player (Ocr-read)
Page 1
2 NW-E503/E505/E507 TABLE OF CONTENTS 1. GENERAL ................................................................... 3 2. DISASSEMBLY 2-1. Disassembly Flow ........................................................... 5 2-2. Lid (Connector) ............................................................... 6 2-3. Cabinet (Inner) ................................................................ 6 2-4. Arm (Shuttle) ................................................................... 7 2-5. Knob (Shuttle) ................................................................. 8 2-6. MAIN Board .................................................................... 9 2-7. Organic El Indicator Module ........................................... 10 3. TEST MODE ............................................................... 11 4. DIAGRAMS 4-1. Block Diagram ................................................................ 13 4-2. Printed Wiring Board – MAIN Board (Side A) – ........... 14 4-3. Printed Wiring Board – MAIN Board (Side B) – ........... 15 4-4. Schematic Diagram – SW Board, MAIN Board (1/5) – 16 4-5. Schematic Diagram – MAIN Board (2/5) – ................... 17 4-6. Schematic Diagram – MAIN Board (3/5) – ................... 18 4-7. Schematic Diagram – MAIN Board (4/5) – ................... 19 4-8. Schematic Diagram – MAIN Board (5/5) – ................... 20 4-9. Printed Wiring Board – SW Board – .............................. 21 5. EXPLODED VIEWS 5-1. Overall-1 ........................................................................\ .. 25 5-2. Overall-2 ........................................................................\ .. 26 6. ELECTRICAL PARTS LIST .................................. 27 Microsoft, Windows and Windows Media are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. US and foreign patents licensed from Dolby Laboratories. All other trademarks and registered trademarks are trademarks or registered trademarks of their respective holders. UNLEADED SOLDER Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size) : LEAD FREE MARK Unleaded solder has the following characteristics. - Unleaded solder melts at a temperature about 40 °C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350 °C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! - Strong viscosity Unleaded solder is more viscou-s (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. - Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. Flexible Circuit Board Repairing - Keep the temperature of the soldering iron around 270 °C during repairing. - Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). - Be careful not to apply force on the conductor when soldering or unsoldering. Notes on chip component replacement - Never reuse a disconnected chip component. - Notice that the minus side of a tantalum capacitor may be damaged by heat. Supplied accessories Headphones (1) Dedicated USB cable (1) Extension headphone cord (NW-E505/E507) (1) Carrying pouch (NW-E505/E507) (1) Clip (1) CD-ROM for the SonicStage software, PDF file Operating Instructions, and PDF file SonicStage Operating Instructions (1) Quick Start Guide Design and specifications are subject to change without notice. Microsoft, Windows and Windows Media are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. \
Page 2
3 NW-E503/E505/E507 SECTION 1 GENERAL This section is extracted from instruction manual. Locating controls For details about each part, refer to the pages in parentheses. Rear side Front side 1 2 3 5 6 4 7 8 9 0 qa 1 Shuttle switch (pages 17 to 22, 25, 27 to 39, 41, 43) 2 Nx button (pages 14 to 25, 27 to 29, 31 to 39, 41, 43) 3 SEARCH/MENU button (pages 15, 17 to 25, 27 to 29, 31 to 39, 41, 43) 4 Display (pages 10, 15, 22, 26, 40) For details on the display and icons, refer to page 10. 5 VOL (Volume) +/– button (pages 14, 33) 6 DISP/FM (Display/FM) button (pages 26 to 27, 40) 7 REPEAT/SOUND button (pages 22 to 24, 28, 41) 8 Strap hole 9 Headphone jack (page 14) q; Reset button (page 46) qa USB jack (page 12) 1 Text/graphic information display (pages 15, 22) Displays album title, artist name, track number, track name, current date and time (pages 26 to 28, 31), MESSAGE (page 50) and menu. Press the DISP/FM (Display/FM) button to switch the display mode (pages 26 to 28). Switch the display to Power Save or Display OFF mode when you do not operate the unit for a while (page 35). 2 Current track number/total track number of the Play Range The track number currently selected or being played back and the total track number of the current Play Range is displayed. 3 Playing status indicator Display current playback mode ( N: playback, x: stop) and elapsed time. 4 Repeat mode indication (page 22) The current repeat mode icon is displayed. 5 Digital sound preset indication (pages 28 to 29) The current digital sound preset is displayed if set. 6 Remaining battery indication (pages 12 to 13) The remaining battery power is displayed. z Tip For information on the FM tuner display, see FM Tuner (page 40). Display Artist 01:23 2 SHUF Track 1 1/32 12 35 46
