– 2 – SECTION 1 EXPLODED VIEW NOTE : - -XX, -X mean standardized parts, so they may have some difference from the original one. - Color indication of Appearance Parts Example : KNOB, BALANCE (WHITE) --- (RED) ↑↑ Parts color Cabinet's color - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.- The mechanical parts with no reference number in the exploded views are not supplied. - Hardware (# mark) list and accessories and packing materials are given in the last of this parts list. - Abbreviation HK : Hong Kong JEW : Tourist The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. 9 1 10 28 27 10 aaMT-MZE900-173 2 11 30 3 12 413 514 626 15 33 725 32 34 16 8 14 18 39 40 17 19 20 21 35 37 3623 3822 3124 29 23 MAIN SECTION
Page 2
– 3 – Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 3-222-225-01 PANEL, BOTTOM - - - - - (SILVER) 1 3-222-225-11 PANEL, BOTTOM - - - - - (BLUE) (HK) 1 3-222-225-21 PANEL, BOTTOM - - - - - (PINK) (HK) 1 3-222-225-31 PANEL, BOTTOM - - - - - (WHITE) (HK) 2 3-222-228-01 KNOB (OPEN) 3 3-222-246-01 ESCUTCHEON *4 A-3322-910-A SW MOUNTED PC BOARD (S) 5 3-222-248-01 KNOB (AVLS) - - - - - (SILVER,WHITE) 5 3-222-248-21 KNOB (AVLS) - - - - - (BLUE) (HK) 5 3-222-248-31 KNOB (AVLS) - - - - - (PINK) (HK) 6 3-222-249-01 KNOB (HOLD) - - - - - (SILVER,WHITE) 6 3-222-249-21 KNOB (HOLD) - - - - - (BLUE) (HK) 6 3-222-249-31 KNOB (HOLD) - - - - - (PINK) (HK) 7 1-679-235-11 SWITCH FLEXIBLE BOARD 8 3-222-226-01 BELT, ORNAMENTAL - - - - - (SILVER) 8 3-222-226-11 BELT, ORNAMENTAL - - - - - (BLUE)(HK) 8 3-222-226-21 BELT, ORNAMENTAL - - - - - (PINK) (HK) 8 3-222-226-31 BELT, ORNAMENTAL - - - - - (WHITE) (HK) 9 3-222-227-01 BUTTON, CONTROL 10 4-218-233-05 SCREW (1.4), MI 11 X-3380-214-1 LID ASSY,UPPER (S) - - - - - (SILVER) 11 X-3380-215-1 LID ASSY,UPPER (L) - - - - - (BLUE) (HK) 11 X-3380-216-1 LID ASSY,UPPER (P) - - - - - (PINK) (HK) 11 X-3380-217-1 LID ASSY,UPPER (W) - - - - - (WHITE) (HK) 12 X-3379-511-1 HOLDER ASSY 13 3-222-373-01 TERMINAL BOARD (MINUS) 14 3-704-197-93 NILOCK M1.4 15 X-3379-509-1 BRACKET (L) ASSY 16 3-049-051-01 SCREW (MD), STEP17 X-3379-505-1 BRACKET (R) ASSY 18 X-3379-506-1 BRACKET (STOP) ASSY 19 3-222-250-01 CASE, BATTERY - - - - - (SILVER,WHITE,PINK) 19 3-222-250-11 CASE, BATTERY - - - - - (BLUE)(HK) *20 A-3323-605-A MAIN BOARD, COMPLETE 21 3-222-243-01 SHEET, INSULATING *22 A-3322-912-A AUDIO BOARD, COMPLETE 23 4-218-229-13 SCREW MI 1.4X1.8 24 3-049-041-01 TERMINAL BOARD 25 X-3379-507-1 TERMINAL (PLUS) ASSY, BATTERY 26 3-222-224-01 LID, BATTERY CASE - - - - - (SILVER) 26 3-222-224-11 LID, BATTERY CASE - - - - - (BLUE) (HK) 26 3-222-224-21 LID, BATTERY CASE - - - - - (PINK) (HK) 26 3-222-224-31 LID, BATTERY CASE - - - - - (WHITE) (HK) 27 3-225-711-01 WINDOW (LED) 28 3-225-712-01 SHEET (LED), ADHESIVE 29 4-218-229-33 SCREW MI 1.4X3.5 30 3-315-751-11 SPACER, KNOB (B) 31 4-963-883-22 SCREW (M1.4), PRECISION PAN 32 3-226-864-01 SHEET (PERCHI 2) 33 3-226-896-01 SPACER (FULCRUM L) 34 3-226-855-01 SHEET (BATTERY CASE), ADHESIVE 35 3-227-252-01 SPACER (BATTERY TERMINAL 2) 36 3-226-809-01 SHEET (REAR) 37 3-226-897-01 SPACER (BATTERY CASE) 38 3-227-153-01 SHEET, ADHESIVE 39 3-227-636-01 WASHER (FITTING BOTTOM) 40 3-226-808-01 SHEET (BOTTOM)
