Page 2
MEX-R1
SECTION 3
DISASSEMBLY
O This set can be disassembled in the order shown below.
3-1.
DISASSEMBLY FLOW
SET (GENERAL SECTION)
l
3-2.
SUB PANEL COMPLETEASSY
(Page 10)
l
3-3.
DVD MECHANISM DECK (MG-612- 187)
(Page 10)
l
l
3-5. CHASSIS (T) SUB ASSY 3-4. MAIN BOARD, DC FAN (25X25) (M901) 3-10. SERVO BOARD
(Page 11) (Page 11) (Page 14)
3-6. ROLLER ARM ASSY 3-9. LE MOTOR ASSY (LOADING) (M3)
(Page 12) (Page 13)
3-7. CHASSIS (OP-DVD) COMPLETE ASSY
(Page 12)
l
3-8.
CHASSIS (OP-DVD) SUB ASSY
(Page 13)
SET (FRONT PANEL SECTION)
l
3-11. FRONT BACK PANEL (LCD)
(Page 14)
l
3- 12. BASE BOARD
(Page 15)
l
3- 13. DISPLAY SECTION
(Page 15)
l
3- 14. BRACKET (DISPLAY)
(Page 16)
l
3-15. SPRING (5)
(Page 16)
10
Note: Follow the disassembly procedure in the numerical order given.
3-2. SUB PANEL COMPLETE ASSY
0 screw
(PTT 2.5 x 6)
0 cover
9 two bosses
9 two claws
6 two claws
0 two screws
(PTT 2.6 x 6)
6 sub panel complete assy
3-3. DVD MECHANISM DECK (MG-612487)
0 dust prolection sheet
e bracket (CD)
0 DVD mechanism deck
(MG-612487)
9 Call/79010!
(CM?)
6 shield (mecha)
9 two screws
(F1.7><2.5)é
(PTT 2.6 x 6)
10
