Page 2

Thank you for purchasing this Sony Network

Audio System. You can enjoy your drive with the

following functions

- Front panel with built-in flash memory
- GIGA PANEL
You can play MP3/WMA files stored in the
front panel with its built-in 1 GB flash memory.
Audio files can be transferred from your
computer to the front panel at high speed by
USB connection (Available OS are Windows
XP and Windows 2000.)

- CD playback
You can play CD-DA (also containing CD
TEXT*), CD-R/CD-RW (MP3/WMA files also
containing Multi Session (page 13)) and
ATRAC CD (ATRAC3 and ATRACSplus
format (page 14)).

Type of discs Label on the disc
CDMFACI CDMIACY
CD-DA

DIGITALAMDIU DIGWALAUDID

Recordable FieWritable

COMM EDMIACY
Mp3 mclmtnunm nIGIrALAuoIo
WMA m
ATRAC CD @CDMEAEY ['Ejfi-EMSDAEI

-Wable

Radio reception

7You can store up to 6 stations per band (FMl,
FMZ, FM3, AMI and AM2)i

7 BTM (Best Tuning Memory): the unit selects
strong signal stations and stores themi

Sound adjustment

7 E03 stage2: You can choose any one of 7
preset equalizer curves.

7050 (Dynamic Soundstage Organizer):
creates a more ambient sound field, using
virtual speaker synthesis, to enhance the
sound of speakers, even if they are installed
low in the door.

7 BBE MP: improves digitally compressed
sound such as MP3 (Only when playing a
CD on this unit.)

Optional unit operation

You can also control optional CDIMD changers

and optional Sony portable devices in addition

to playing with this unit.

* A CD TEXT disc is a CD-DA that includes

information such as disc, artist and track name.

For installation and connections, see the
supplied installation/connections manual.

This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:

7 Reorient or relocate the receiving antenna.

7 Increase the separation between the equipment
and receiver.

7 Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.

7 Consult the dealer or an experienced radio/T V
technician for help.

You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate this
equipment.

CAUTION
The use of optical instruments with this product
will increase eye hazard

Warning if your cars ignition has no
ACC position

After turning the ignition off, be sure to press
and hold on the unit until the display
disappears.

Otherwise, the display does not turn off and
this causes battery drain.

Sony is not responsible for damaged data
due to problems of the GIGA PANEL or
computer.
