MDX-60

SERVICE MANUAL um,

Canadian Model
AEP Model

UK Model

E Model

This set is automatic electrical adjustment, _ _
Model Name Usmg Similar Mechanism NEW
Base Mechanism Type MG-798-133
Optical Pick-Up Name KMS-1938/J
SPECIFICATIONS
System Mini disc digital audio system Supplied accessories
Frequency response Mounting hardware (1 set)
20 - 20,000 Hz Bus cable 55 m (1)
Wow and flutter RCA pin cord 5.5 in (1)
_ 3310 {maslrable hm - US. and foreign patents licensed from Dolby
Signa1 95 dB - Design and specifications subject to change without
Outputs Bus control output (8 PIN) notice.

Analog audio output (RCA PIN)
Current drain

300 mA (MD playback)

600 mA (during loading or ejecting a disc)
Dimensions

Approx. 176 x 83.5 X 125 mm (w/h/d)

not incl. projecting parts and controls
Mass Approx. 1.1 kg
Power requirement

12 V DC car battery

(negative ground)

MINIDISC CHANGER SYSTEM
