Sony mds ja 333 es service manual
This is the 95 pages manual for sony mds ja 333 es service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony mds ja 333 es service manual (Ocr-read)
Page 1
2 SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. ATTENTION AU COMPOSANT AYANT RAPPORT Ë LA SƒCURITƒ! LES COMPOSANTS IDENTIFƒS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHƒMATIQUES ET LA LISTE DES PIéCES SONT CRITIQUES POUR LA SƒCURITƒ DE FONCTIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIéSES SONY DONT LES NUMƒROS SONT DONNƒS DANS CE MANUEL OU DANS LES SUPPƒMENTS PUBLIƒS PAR SONY. After correcting the original service problem, perform the following safety checks before releasing the set to the customer: Check the antenna terminals, metal trim, ÒmetallizedÓ knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturersÕ instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The ÒlimitÓ indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2V AC range are suitable. (See Fig. A) SAFETY CHECK-OUT To Exposed Metal Parts on Set 0.15 µF 1.5 k ½ AC Voltmeter (0.75 V) Earth Ground Fig. A. Using an AC voltmeter to check AC leakage. CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufactureÕs instructions. ADVARSEL! Lithiumbatteri - Eksplosionsfare ved fejlagtig hŒndtering. Udskiftning mŒ kun ske med batteri af samme fabrikat og type. LevŽr det brugte batteri tilbage til leverand¿ren. ADVARSEL Eksplosjonsfare ved feilakting skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten. Brukte batterier katterier kasseres i henhold til fabrikantens VARNIG Explosionsfara vid felaktigt batteribyte. AnvŠnd samma batterityp eller en likvŠrdig typ som rekommenderas av apparattillverkaren. Kassera anvŠnt batteri enligt gŠllande fšreakrifter. VAROITUS Parist voi rŠjŠhtŠŠ, jos se on virheellisesti asennettu. Vaihda paristo ainoastaan laitevalmistajan suosittelemaan tyyppiin. HŠvitŠ kŠytetty paristo valmistajan ohjeiden mukaisesti. DIGITAL OUT OPTICAL Connector type: square optical Rated output: Ð18 dBm Load impedance: 660 nm (optical wave length) DIGITAL OUT COAXIAL Jack type: phono Rated output: 0.5 Vp-p (at 75 W) Load impedance: 75 W General Power requirements Where purchased Power requirements US, Canadian 120 V AC, 60 Hz AEP, UK 230 V AC, 50/60 Hz Power consumption20 W Dimensions (approx.)430 ´ 123.5 ´ 375.5 mm (17 ´ 4 7/8 ´ 14 7/8 in.) (w/h/d) incl. projecting parts and controls Mass (approx.)10.5 kg (23 lbs 15 oz) Supplied accessories ¥ Audio connecting cords (2) ¥ Optical cable (1) ¥ Remote commander (remote) (1) ¥ R6 (size-AA) batteries (2) Design and specifications are subject to change without notice.
Page 2
3 This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. The following caution label is located inside the unit. Laser component in this product is capable of emitting radiation exceeding the limit for Class 1. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Notes on chip component replacement ¥ Never reuse a disconnected chip component. ¥ Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing ¥ Keep the temperature of soldering iron around 270ûC during repairing. ¥ Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). ¥ Be careful not to apply force on the conductor when soldering or unsoldering. MODEL IDENTIFICATION Ñ BACK PANEL Ñ Parts No. 4-228-930-1 : AEP, UK model 4-228-930-2 : US model 4-228-930-3 : Canadian model TABLE OF CONTENTS 1. SERVICING NOTE ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááááá 6 2. GENERAL ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááááááááááááááááááá 12 3. DISAssembly 3-1. Case ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááááááááááááááááááááááááááááá 16 3-2. Loading Panel ááááááááááááááááááááááááááááááááááááááááááááááááááá\ áááááááááááááááá 16 3-3. Front Panel Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\ áááá 17 3-4. MD Mechanism Deck ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááá 17 3-5. Tray Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááááááááááááá 18 3-6. BU Holder Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááá 19 3-7. Motor (Loading) Assembly (M10) ááááááááááááááááááááááááááááááááááá 19 3-8. Base Unit (MBU-5J) ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááá 20 3-9. BD Board ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááááááááááááááááááááá 20 3-10. Over Light Head (HR901) áááááááááááááááááááááááááááááááááááááááááááááááá 21 3-11. Mini Disc Device (KMS-260B/J1N) áááááááááááááááááááááááááááááááá 21 4. TEST MODE ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááááááááááááááá 22 5. ELECTRICAL ADJUSTMENTS ááááááááááááááááááááááááááááááá 27 6. DIAGRAMS 6-1. Block Diagrams ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááááááááááá 37 Main Section ááááááááááááááááááááááááááááááááááááááááááááááááááá\ áááááááááááááááááá 37 Display/Power Supply Section ááááááááááááááááááááááááááááááááááááááááá 38 6-2. Circuit Board Location ááááááááááááááááááááááááááááááááááááááááááááááááááá\ áá 39 6-3. Printed Wiring Board BD Section áááááááááááááááááááááááááááááááááá 40 6-4. Schematic Diagram BD Section (1/2) ááááááááááááááááááááááááááá 41 6-5. Schematic Diagram BD Section (2/2) ááááááááááááááááááááááááááá 42 6-6. Schematic Diagram BD Switch Section áááááááááááááááááááááááá 43 6-7. Printed Wiring Board BD Switch Section ááááááááááááááááááááááá 43 6-8. Printed Wiring Board AD Section áááááááááááááááááááááááááááááááá 44 6-9. Schematic Diagram AD Section áááááááááááááááááááááááááááááááááááá 45 6-10. Printed Wiring Board DIO Section áááááááááááááááááááááááááááááá 46 6-11. Schematic Diagram DIO Section áááááááááááááááááááááááááááááááááá 47 6-12. Printed Wiring Board DA Section ááááááááááááááááááááááááááááááááá 48 6-13. Schematic Diagram DA Section ááááááááááááááááááááááááááááááááááá 49 6-14. Printed Wiring Board DIGITAL Section ááááááááááááááááááááááá 50 6-15. Schematic Diagram DIGITAL Section áááááááááááááááááááááááá 51 6-16. Schematic Diagram HP Section ááááááááááááááááááááááááááááááááááá 52 6-17. Printed Wiring Board HP Section áááááááááááááááááááááááááááááááá 53 6-18. Schematic Diagram POWER Section áááááááááááááááááááááááááá 54 6-19. Printed Wiring Board POWER Section áááááááááááááááááááááááá 55 6-20. Printed Wiring Board PANEL Section ááááááááááááááááááááááááá 56 6-21. Schematic Diagram PANEL Section áááááááááááááááááááááááááááá 57 6-22. Printed Wiring Board AC Section áááááááááááááááááááááááááááááááá 58 6-23. Schematic Diagram AC Section ááááááááááááááááááááááááááááááááááá 59 6-22. IC Block Diagrams ááááááááááááááááááááááááááááááááááááááááááááááááááá\ áááááááá 61 6-23. IC PinFunction Description áááááááááááááááááááááááááááááááááááááááááááááá 66 7. EXPLODED VIEWS 7-1. Upper Case Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááá 73 7-2. Front Panel Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\ áááá 74 7-3. Chassis Assembly ááááááááááááááááááááááááááááááááááááááááááááááááááá\ áááááááááá 75 7-4. Mechanism Deck Assembly-1 (MDM-6J) ááááááááááááááááááááááá 76 7-5. Mechanism Deck Assembly-2 (MDM-6J) ááááááááááááááááááááááá 77 7-6. Base Unit (MBU-5J) ááááááááááááááááááááááááááááááááááááááááááááááááááá\ ááááá 78 8. ELECTRICAL PARTS LIST ááááááááááááááááááááááááááááááááááááááá 79
