– 2 – ACCESSORIES & PACKING MATERIALS ******************************** 551 X-4950-550-1 STAND SUB ASSY (for DP-IF5100) 0552 1-528-929-11 BATTERY CHARGER (BC-34HNL) (US,CND,E92) 0552 1-528-930-11 BATTERY CHARGER (BC-34HNL) (AEP,UK,E13,HK) 0553 1-467-817-11 ADAPTOR, AC (AC-S911) (for DP-IF5100) (US,CND,E92) 0553 1-473-581-11 ADAPTOR, AC (AC-S911) (for DP-IF5100) (AEP,E13) 0553 1-473-582-11 ADAPTOR, AC (AC-S911) (for DP-IF5100) (UK,HK) 554 1-783-868-61 CORD, CONNECTION (OPTICAL DIGITAL CONNECTING CABLE) 0555 1-790-368-11 CORD, POWER (for BATTERY CHARGER) (UK,HK) 0555 1-790-369-11 CORD, POWER (for BATTERY CHARGER) (AEP,E13) 3-043-018-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH, SPANISH) 3-043-018-21 MANUAL, INSTRUCTION (GERMAN,DUTCH, ITALIAN,PORTUGUESE) (AEP) 3-043-019-01 INFORMATION, PRODUCT (JAPANESE,ENGLISH, FRENCH,GERMAN,SPANISH,DUTCH, ITALIAN,PORTUGUESE) 4-213-922-01 SCREW, COIN (for STAND) 4-984-729-01 FOOT, RUBBER (for DP-IF5100) PARTS LIST Sony Corporation Personal Audio Division Company 2000B0464-1 Printed in Japan C2000. 2 Published by General Engineering Dept. 9-927-601-12 Ref. No. Part No. Description Remark Supplied accessories Stand for digital surround processor (1) AC power adapter (9 V) AC-S911 (1) Rechargeable Ni-Cd batteries (NC-AA) (2) Battery charger BC-34HNL (1) Charging plug for battery charger (1) Optical digital connecting cable (rectangular plug y rectangular plug, 1.5 m) (1) Operating Instructions (1) Product Information (1) Design and specifications are subject to change without notice. Note)The designations of the parts in the figure are just as described in the instruction manual. The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une piéce portant le numéro spécifié. - Abbreviation CND : Canadian model E13 : AC220-230V area in E model E92 : AC120V area in E model HK : Hong Kong model 551 552 553 554 555 555Stand (for digital surround processor, 1)Battery charger (1) AC power adapter (1) Optical dijital connecting cable (rectangular type rectangular type, 1) Charging plug (for battery charger,1 (UK, HK model)Charging plug (for battery charger,1 (AEP, E13 model)
