Sony mdr ds 3000 service manual
This is the 4 pages manual for sony mdr ds 3000 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony mdr ds 3000 service manual (Ocr-read)
Page 1
2 MDR-DS3000 Ref. No. Part No. Description Remark ACCESSORIES Note:The description used in the figure are those contained in the instruction manual. ACCESSORIES *********** 0 101 1-473-579-12 ADAPTOR, AC (AC-S906) (AEP, E) 0 101 1-473-582-13 ADAPTOR, AC (AC-S911) (UK) 0 101 1-476-380-12 ADAPTOR, AC (AC-S911T) (UK) 0 101 1-478-498-11 ADAPTOR, AC (AC-S905) (KR) 0 101 1-693-007-21 ADAPTOR, AC (AC-S195) (JE) 0 101 1-693-029-11 ADAPTOR, AC. (AC-S906T) (US,CND) 102 1-756-316-21 BATTERY, NICKEL.HYDROGEN (BP-HP550) (US,CND) 102 1-756-316-31 BATTERY, NICKEL.HYDROGEN (BP-HP550) (EXCEPT US,CND) 103 1-783-868-62 CORD, CONNECTION 0 1-569-008-12 ADAPTOR, CONVERSION 2P (JE) 3-258-321-12 MANUAL, INSTRUCTION (ENGLISH, FRENCH, SPANISH, KOREAN) 3-258-321-21 MANUAL, INSTRUCTION (GERMAN, DUTCH, ITALIAN, PORTUGUESE) (AEP) Ver 1.1 - Abbreviation CND : Canadian model KR : Korean model JE : Tourist model AC power ad aptor (1) Optica l digital connecting cable (r ectangular type y re ctan gular type) (1) Re charge able nickel-metal hydride batteries BP -HP 550 (2) 101 102 103 The components identified by mark 0 or dotted line with mark 0 are critical for safety. Replace only with part number specified. Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié.
Page 2
3 MDR-DS3000 MEMO
