Sony mdr 7502 service manual

Page 1

Ð 2 Ð 3. EXPLODED VIEW AND PARTS LIST NOTE : ¥ -XX, -X mean standardized parts, so they may have some difference from the original one. ¥ Items marked Ò * Óare not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items.¥ The mechanical parts with no reference number in the exploded views are not supplied. Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 1 X-2113-123-1 PAD ASSY, EAR 2 X-2113-120-1 FRONT BOARD ASSY (030F014) (FORMER TYPE) 2 X-4951-140-1 FRONT BOARD ASSY (030F030P) (NEW TYPE) 3 2-115-667-01 PAD, EAR 4 2-113-154-01 BUSHING 5 4-942-718-01 HOUSING 6 2-113-162-01 HANGER 7 7-685-102-19 SCREW +P 2X4 TYPE2 SLIT 8 X-2113-121-1 HEAD BAND ASSY9 2-113-157-01 LID, HANGER 901 1-580-791-21 CORD 902 1-506-589-11 ADAPTOR, PLUG ************************************************************ ACCESSORIES & PACKING MATERIALS ******************************* *4-942-596-01 INDIVIDUAL CARD BOARD (NEW TYPE) 9-956-093-14 Sony Corporation Personal A&V Products Company 98L0256-1 Printed in Japan © 1998.12 Published by Quality Engineering Dept. (Shibaura) 3 1 1902901 2 4 45 56 68 7 7 7 7 3 7 72 9 9 (NEW TYPE) not suppliednot supplied not supplied not supplied FORMER TYPE
