MDP-44Il/B4IID/74IID
EMT-333E
SERVICE MANUAL
AEP Model
Photo: MOP-7400
Type
Signal readout
Signal format
Playing time
CD/CDV/LD Player
Optical (Laser beam reflection)
CCIR standard, PAL colour system
EIA standard, NTSC colour system
SPECIFICATIONS
PAL NTSC
30 cm (12 in)
double-sided 72 60
20 cm (8 in) ,
CAV double-sided 32 28
20 cm (8 in) _ 14
single-sided
LD 30 cm (12 in) 120 120
double-sided
20 cm (8 in)
CI-V double-sided 40 4O
20 cm (8 in)
single-sided _ 20
Audio portion 20 20
CDV Video portion 6 5
12 cm (5 in)
singlesided 74 74
CD s cm (a in) 20 20
singlesided
(minutes)
Digital audio specifications
Frequency response
4 Hz to 20 kHz (:03 dB)
Signal-to-noise ratio
More than 100 dB (ElAJ)
Dynamic range More than 95 dB (ElAJ')
Total harmonic distortion
0.003% or less (EIAJ at 1 kHz)
Channel separation
More than 90 dB (EIAJ' at 1 kHz)
Wow and flutter Below measurement limit
(:0.001% W.PEAK) (EIAJ)
Measurement by under condition of standards of Electric
industries Association of JAPAN (VTC-015)
Horizontal video resolution
PAL 440 lines
NTSC 425 lines
- Continued on next page -
o SERVICE OF REMOTE COMMANDER EMT-333E
Remote commander RMT-333E is available
as a unit. But as individual parts the battery
case lid of commander is only available.
€90 CD/BDV/LD/PLAYER
