Sony mdp 333 mdp 355gx service manual
This is the 98 pages manual for sony mdp 333 mdp 355gx service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony mdp 333 mdp 355gx service manual (Ocr-read)
Page 2
Power requlrements
Power requirements MDP~333z 120 V AC, 60 Hz
MDP-355GX:
100/120/220/240 V AC
adjustable, 50/60 Hz
40 W
8 kg (16 lb 12 02)
Power consumption
Weight
Dimensions
(w/h/d)
(17 X 4W, x 17 inches)
Operating temperature +5°C to +35°C
Ambient humidity 5 to 90%
Measured according to EIAJ (Electronic Industries
Association of Japan) standards.
Remote Commander EMT-333A
Principle of operation Infrared pulse
Power requirements 3 V DC (2 size AA batteries)
Approx. 430 X 115 X 420 mm
Dimensions Approx. 62 X 44.5 x 185 mm
(w/h/d)
(27/15 >< 13/15 >< 73/3 inches)
Weight Approx. 170 9 (including
batteries), (6 oz)
l Supplied. accessories
Remote Commander EMT-333A (1)
Size AA (R6) batteries (2)
RFU adaptor FIFU-90 UC (1) (supplied with the MDP-333
and the PX model of MDP-sssGX)
Video connecting cord (phono plug 1 4-) phono plug 1) (1)
Audio connecting cord (phono plug 2 e» phono plug 2) (1)
Operating Instructions
Spacer (1)
AC plug adaptor (MDP-SSSGX only) 1
Design and specifications are subject to change without
notice.
WARNING II
WHEN SERVICING, DO NOT APPROACH THE LASER
EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS
NECESSARY TO CONFIRM LASER BEAM EMISSION,
BE SURE TO OBSERVE FROM A DISTANCE OF MORE
THAN 25 cm FROM THE SURFACE OF THE OBJECTIVE
LENS ON THE OPTICAL PICK-UP BLOCK.
CAUTION:
The use of optical instrument with this product will
increase eye hazard.
CAUTION
Use of controls or adjustments or performance
of procedures other than those specified herein
may result in hazardous radiation exposure.
SAFETY»RELATED COMPONENT WARNINGI!
COMPONENTS IDENTIFIED BV MARK A 0R DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONV.
ATTENTION AU COMPOSANT AYANT RAPPORT
A LA SECURITE!
LES COMPOSANTS IDENTIFIES PAR UNE MAROUE A
SUR LES DIAGRAMMES SCHEMATIOUES ET LA LISTE
05s PIECES SONT CRITIOUEs POUR LA SECURITE
DE FONCTIONNEMENT. NE REMPLACEFI css COM-
PosANTs OUE PAR DES PIECES SONv DONT LES
NUMEROS SONT DONNEs DANS CE MANUEL 0U
DANS LES SUPPLEMENTS PUBLIES PAR soNv.
