Sony icf b 200 service manual
This is the 14 pages manual for sony icf b 200 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony icf b 200 service manual (Ocr-read)
Page 1
– 2 – mark1 mark2Center Frequency red 10.70 MHz blue 10.67 MHz orange 10.73 MHz black 10.64 MHz white 10.76 MHz white white 10.75 MHz yellow 10.79 MHz HOW TO CHANGE THE CERAMIC FILTERS This model is used two ceramic filters of CF1 and CF3. You must use same type of color marked ceramic filters in order to meet same specifications. Therefore, the ceramic filter must change two pieces together since its supply two pieces in one package as a spare parts. TABLE OF CONTENTS 1. GENERAL Power Sources ........................................................................ 3 Playing the Radio ................................................................... 3 Useful functions ..................................................................... 3 2. SERVICE NOTE ............................................................... 4 3. DISASSEMBLY 3-1. Cabinet (Rear) Assy ........................................................... 5 3-2. Main Board Assy ................................................................ 5 3-3. Main Board ........................................................................ 6 3-4. Pointer Setting .................................................................... 6 4. ELECTRICAL ADJUSTMENTS ................................. 7 5. DIAGRAMS 5-1. Printed Wiring Boards ........................................................ 9 5-2. Schematic Diagram .......................................................... 11 6. EXPLODED VIEWS 6-1. Cabinet (Rear) Section ..................................................... 13 6-2. Cabinet (Front) Section .................................................... 14 7. ELECTRICAL PARTS LIST................................... 15 mark1 mark2 mark1 mark2 CF3 CF1
Page 2
– 3 – SECTION 1 GENERAL This section is extracted from instruction manual.
