Sony icd 55 service manual
This is the 19 pages manual for sony icd 55 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony icd 55 service manual (Ocr-read)
Page 1
Ð 2 Ð TABLE OF CONTENTS 1. SERVICING NOTES ............................................... 2 2. GENERAL ................................................................... 3 3. DISASSEMBLY ......................................................... 4 4. DIAGRAMS 4-1. Block Diagram ................................................................ 7 4-2. Printed Wiring Board ...................................................... 9 4-3. Schematic Diagram ......................................................... 11 4-4. IC Pin Function Description ........................................... 17 5. EXPLODED VIEW ................................................... 19 6. ELECTRICAL PARTS LIST ............................... 20CAUTION ON REPLACING FLASH MEMORY The BAD-BLOCK check* must be executed, when the flash memory in this set was replaced. The set will not operation normally, unless this check is finished. * The BAD-BLOCK check detects an area (bad-block) in the flash memory where data validity cannot be guaranteed, and saves this information in the TOC-AREA so that a bad-block is not used. BAD-BLOCK check Procedure: 1. Apply 1.5V from regulated power supply to the battery termi- nals. 2. Once the power is supplied, the check starts and then proceeds for approx. 20 seconds. (Be sure to keep applying the power during the check) 3. When the check completes, the result is shown as bellows. OK: Only the LCD back light LED (D503) turns on. NG: Red LED blinks or turns on or green LED turns on in the OPR LED (D504). 4. In case of OK, press the [STOP] button. Note: ¥ In case of NG, check system control IC (IC701), flash memory IC and the peripheral circuit. (Particularly, check carefully the soldering of the flash memory) ¥ After finishing the BAD-BLOCK check, assemble the set, load the dry battery, and confirm if the set operates normally. Notes on chip component replacement ¥ Never reuse a disconnected chip component. ¥ Notice that the minus side of a tantalum capacitor may be dam- aged by heat. Flexible Circuit Board Repairing ¥ Keep the temperature of the soldering iron around 270 ûC dur- ing repairing. ¥ Do not touch the soldering iron on the same conductor of the circuit board. (within 3 times) ¥ Be careful not to apply force on the conductor when soldering or unsoldering. SECTION 1 SERVICING NOTES
Page 2
Ð 3 Ð SECTION 2 GENERAL This section is extracted from instruction manual.
