Ð 2 Ð TABLE OF CONTENTS 1. SERVICING NOTES ............................................... 3 2. GENERAL Location of Controls ....................................................... 4 Setting the Time .............................................................. 6 3. DISASSEMBLY ......................................................... 7 4. TEST MODE .............................................................. 15 5. MECHANICAL ADJUSTMENTS ........................ 17 6. ELECTRICAL ADJUSTMENTS TAPE DECK Section ...................................................... 17 CD Section ...................................................................... 20 7. DIAGRAMS 7-1. IC Pin Function Description ........................................... 22 7-2. Block Diagram Ð CD Section Ð ..................................... 27 7-3. Block Diagram Ð TAPE DECK Section Ð ..................... 29 7-4. Block Diagram Ð MAIN Section (1/2) Ð ....................... 31 7-5. Block Diagram Ð MAIN Section (2/2) Ð ....................... 33 7-6. Block Diagram Ð DISPLAY/KEY CONTROL/ POWER SUPPLY Section Ð ........................................... 35 7-7. Printed Wiring Board Ð CD Section (1/2) Ð .................. 39 7-8. Schematic Diagram Ð CD Section (1/2) Ð ...................... 41 7-9. Printed Wiring Boards Ð CD Section (2/2) Ð ................ 43 7-10. Schematic Diagram Ð CD Section (2/2) Ð ...................... 45 7-11. Printed Wiring Boards Ð TAPE DECK Section Ð ......... 47 7-12. Schematic Diagram Ð TAPE DECK Section Ð ............... 49 7-13. Printed Wiring Board Ð MAIN Section Ð ...................... 51 7-14. Schematic Diagram Ð MAIN Section (1/3) Ð ................. 53 7-15. Schematic Diagram Ð MAIN Section (2/3) Ð ................. 55 7-16. Schematic Diagram Ð MAIN Section (3/3) Ð ................. 57 7-17. Printed Wiring Board Ð POWER AMP Section Ð ......... 59 7-18. Schematic Diagram Ð POWER AMP Section Ð ............. 61 7-19. Printed Wiring Board Ð PANEL Section (1/3) Ð ........... 63 7-20. Schematic Diagram Ð PANEL Section (1/3) Ð ............... 65 7-21. Printed Wiring Boards Ð PANEL Section (2/3) Ð .......... 67 7-22. Schematic Diagram Ð PANEL Section (2/3) Ð ............... 69 7-23. Printed Wiring Boards Ð PANEL Section (3/3) Ð .......... 71 7-24. Schematic Diagram Ð PANEL Section (3/3) Ð ............... 73 7-25. Printed Wiring Board Ð POWER SUPPLY Section Ð ........................................ 75 7-26. Schematic Diagram Ð POWER SUPPLY Section Ð ........................................ 76 8. EXPLODED VIEWS ................................................ 81 9. ELECTRICAL PARTS LIST ............................... 90 Tape player section Recording system 4-track 2-channel stereo Frequency response (DOLBY NR OFF) 60 - 13,000 Hz (±3 dB), using a Sony TYPE I cassette 60 - 14,000 Hz (±3 dB), using a Sony TYPE II cassette Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner sectionTuning range 87.5 - 108.0 MHz (50 kHz step) Antenna FM wire antenna Antenna terminals 75 ohm unbalanced Intermediate frequency 10.7 MHz AM tuner sectionTuning range (2 band model) 531 - 1,602 kHz (with the tuning interval set at 9 kHz) 530 - 1,710 kHz (with the tuning interval set at 10 kHz) (3 band model ) MW: 531 -1,602 kHz (with the tuning interval set at 9 kHz) LW: 153 - 279 kHz (with the tuning interval set at 3 kHz) Antenna AM loop antenna, External antenna terminals Intermediate frequency 450 kHz General Power requirements Mexican model: 120 V AC, 50/60 Hz Australian and South African models: 220 - 240 V AC, 50/60 Hz Other models: 110 -120 V or 220 -240 V AC, 50/60 Hz Adjustable with voltage selector Power consumption 320 watts Dimensions (w/h/d) Approx. 355 ´ 425 ´ 435 mm (14 ´ 16 3/4 ´ 17 1/4 in) incl. projecting parts and controls Mass Approx. 14.5 kg (31 lb 16 oz.) Supplied accessories AM loop antenna (1) Remote RM-SD70S (1) Size AA (R6) batteries (2) FM wire antenna (1) Speaker cords (2) Design and specifications are subject to change without notice.
