Sony hcd x 1 service manual

Page 1

2 HCD-X1 ATTENTION AU COMPOSANT AYANT RAPPORT À LA SÉCURITÉ! LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0 SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REMPLACER CES COM- POSANTS Q UE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PA RT NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Notes on chip component replacement - Never reuse a disconnected chip component. - Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing - Keep the temperature of the soldering iron around 270 ˚C during repairing. - Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). - Be careful not to apply force on the conductor when soldering or unsoldering. CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation e xposure. SAFETY CHECK-OUT After correcting the original service problem, perform the following safety check before releasing the set to the customer: Check the antenna terminals, metal trim, metallized knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. LEAKAGE TEST The AC leakage from any exposed metal part to earth ground and from all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes.). Leakage current can be measured by any one of three methods. 1. A commercial leakage tester, such as the Simpson 229 or RCA WT-540A. Follow the manufacturers instructions to use these instruments. 2. A battery-operated AC milliammeter. The Data Precision 245 digital multimeter is suitable for this job. 3. Measuring the voltage drop across a resistor by means of a VOM or battery-operated AC voltmeter. The limit indication is 0.75 V, so analog meters must have an accurate low-voltage scale. The Simpson 250 and Sanwa SH-63Trd are examples of a passive VOM that is suitable. Nearly all battery operated digital multimeters that have a 2 V AC range are suitable. (See Fig. A) Fig. A. Using an AC voltmeter to check AC leakage. 1.5 k Ω 0.15 µF AC voltmete r (0.75 V) To Exposed Metal Parts on Set Earth Ground This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the bottom of the unit. Tuner section System PLL quartz-locked digital synthesizer system FM t uner section Tuning range 87.5 – 108.0 MHz US, Canadian models: (100 kHz step) except US, Canadian models: (50 kHz step) US, Canadian mode ls: 530 – 1,710 kHz (with the Antenn a (aerial) FM wire antenna (aerial) Antenna (aerial) terminals 75 ohms, unbalanced Intermediate fr equency10.7 MHz AM tu ner section Tuning range interval set at 10 kHz) 531 – 1,710 kHz (with the interval se t at 9 kHz) AEP, UK, Russian models: 531 – 1,602 kHz (with the interval set at 9 kHz) Singapore model: 531 – 1,602 kHz (9 kHz) 530 – 1,710 (10 kHz) Antenn a (aerial) AM loop antenna (aerial) In termediate frequency 450 kHz Video section Outputs Video: 1 Vp-p 75 ohms S video: Y: 1 Vp-p 75 ohms C: 0.286 V p-p 75 ohms CO MPONENT: Y: 1 Vp-p 75 ohms PB/CB, PR/CR: 0.7 Vp-p 75 ohms Input VIDEO: 1 Vp-p 75 ohms S video: Y: 1 Vp-p 75 ohms C: 0.286 V p-p 75 ohms General Power re quirements US, Canadian models: 120 V AC, 60 Hz except US, Canadian models: 220 – 240 V AC, 50/60 Hz Power co nsumption On: 85 W Stan dby: 0.3 W (at the Power Saving Mode) Dimensions (approx.) 380 × 76 × 293 mm (15 × 3 × 11 5/8 inches) (w/ h/d) incl. projecting parts Mass (approx.) US, Canadian models: 4.6 kg (10 lb 3 oz) except US, Canadian models: 4.5 kg Design and specifications are subject to change without notice.
