Page 2

HCD-H1 60/H600

Compact Disc Player Section

System Compact disc digital audio

system

Laser Semiconductor laser

(A = 780 nm)

Emission duration:

continuous

Max. 44.6 uW*

* This output is the value
measured at distance of
about 200 mm from the
objective lens surtace on
the Optical Pick-up Block.

Laser output

Cassette Deck Section

Recording system 4-track 2-channel stereo
Frequency response (DOLBY NFI OFF)
40 -1a,ooo Hz(18 dB),
using TYPE 1 cassette
(Sony HF»S)
40 -14.000 Hz (:3 dB),
using TYPE ll cassette

Wow and flutter 0.1% WRMS 10.3% (DIN)

General

Power requirements AEP model:
220 - 230 V, 50/60 HZ
U K model: 240 V, 50 Hz ,
Germany, Italian model: 240V AC, 50H:
Power consumption Except lor model: 90 watts
U K model: 160 watts
Approx. 615 x 285 x 250 mm
(w/h/d)
(24V: X11/4 >< 10% inches)
incl. projec1ing parts and
controls
Weight Approx. 12.6 kg (27 lb 12 oz)
Supplied accessories
Remote commander (RM-S100) (1)
Sony SUM-3 (NS)
batteries (2)
AM loop antenna (1)
FM lead antenna (1) (HCD-
HGOO only)

Dimensions

Design and specifications subject to change
without notice.

Note
This appliance conforms With EEC Directive
87/308/EEC regarding interierence suppression.

TABLE OF CONTENTS

Swift-n fltLe figs:
SECTION 1 SERVICING NOTES .................................... 3
SECTION 24 GENERAL
SECTION 3_ DISASSEMBLY ....................................... 21
SECTION 4. BLOCK DIAGRAM
4.,_ Mai Block ................................................... 23
44, CD Block ................................................. 25

SECTION 5. MECHANICAL ADJUSTMENT

SECTION 6. ELECTRICAL ADJUSTMENT --------------------- 29
SECTION 7. DIAGRAMS
7.1_ Semiconductor Lead by; .............................. 35
7.2» cm, Boards Location .................................... 36

73. Printed Wiring;I Boards-TunerIDeck/CD Section-"- 39
7-4. Schematic Diagrams-Tuner/Deck Section- --------- 43
7-5. Schematic Diagrams

~Powu/Amplifier/Display Section~ - ----------- 47

76. Printed Wiring Boards

-Power/Amplifier/Display Section - ............ 51
7»7. Schematic Diagrams -CD Section - ------------------ 54
7.3_ Pin Functions ................. . ................................. 61

SECTION 8. EXPLODED VIEWS

8~1i Case, Power Section - 67
8-2. Front Panel. Main Board Section ............. 68
3.3. MD Giassis Section .......................................... 69
8.4. Mechanism Deck Section (1) .............................. 70
8-5, McChanism Deck Section (2) .................. . ........... 71
8-6. CD Section (1)
3.7, CD Section (2) ................................................ 73
SECTION 9. ELECTRICAL PARTS LIST ---------------------- 74

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BY MARK A OR DOTTED
LINE WITH MARK A ON THE SCHEMATIC DIAGRAMS
_AND IN THE PARTS LIST ARE CRITICAL TO SAFE

OPERATION.

REPLACE THESE COMPONENTS WITH

SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
