Page 2

HCD-GZR88DIGZR99D
Ver. 1.1

Inputs
VIDEO/SAT VIDEO IN (phono jack):
1 Vp-p, 75 ohms
VIDEO/SAT AUDIO IN L/R (phonojacks):
voltage 250/450 mV, impedance 47 kilohms
MIC l/MIC 2 (phonejacks):
sensitivity 1 mV, impedance 10 kilohms

Outputs
VIDEO OUT (phono jack):
max. output level 1 Vp-p, unbalanced,
Sync negative, load impedance 75 ohms
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
PB/CE: 0.7 Vp-p, 75 ohms
PR/CR: 0.7 Vp-p, 75 ohms
DVD DIGITAL OUT (Square optical connectorjack, rear panel):
Wavelength 650 nm
PHONES (stereo minijack):
accepts headphones ofS ohms or more
SUBWOOFER OUT (MHC-GZRSSD only):
Voltage 1 V, impedance 1 kilohm
FRONT SPEAKER: Use only the supplied speaker SS-GZR99D.
SATELLITE SPEAKER: Use only the supplied speaker SS-RSX99D.
SUBWOOFER (MHC-GZRQQD only):
Use only the supplied subwoofer
SS-WGV99D.
6' (USB) port: Type A (1)
Maximum current: 500 mA

Disc player section
System: Compact disc and digital audio and video
system
Laser Diode Properties
Emission duration:
Continuous Laser Output:
Less than 44.6pW
*This output is the value measurement
at a distance of 200mm from the objective
lens surface on the Optical Pick-up Block
with 7mm aperture.
Frequency response
DVD (PCM 48 kHz): 2 Hz 7 22 kHz (i1 dB)
CD: 2 Hz 7 20 kHz (3:0.5 dB)
Video color system format
Latin American model: NTSC
Other models: NTSC and PAL

Tape deck section (except for Latin American models)
Recording system: 4-track 2-channel, stereo

Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range: 87.5 7 108.0 MHz (50 kHz step)
Antenna: FM lead antenna
Antenna terminals: 75 Q unbalanced
Intermediate frequency:
10.7 MHz
AM tuner section
Tuning range:
Saudi Arabian models:
531 7 1,602 kHz (9 kHz step)
Latin American model:
530 7 1,710 kHz (with 10 kHz tuning interval)
531 7 1,710 kHz (with 9 kHz tuning interval)
531 7 1,602 kHz (with 9 kHz tuning interval)
530 7 1,610 kHz (with 10 kHz tuning interval)
Antenna: AM loop antenna
Antenna terminals: External antenna terminal
Intermediate frequency:
450 kHz

Other models:

General
Power requirements
Argentine and Thai models:
AC 220 V, 50/60 Hz
Saudi Arabian model:
AC 120 7 127. 220, 230 7 240 V, 50/60 Hz,
adjustable with voltage selector
AC 127 V, 60 Hz,
AC 120,220, 230 7 240 V, 50/60 Hz,
adjustable with voltage selector
Power consumption
MHC-GZR99D: 215 W
MHC-GZR88D: 170 W
Dimensions (w/h/d) (excl. speakers):
Approx. 280 x 326 x 440 mm
Mass (excl. speakers)

Mexican model:
Other models:

MHC-GZR99D: Approx. 13.2 kg (Latin American models),
approx. 13.7 kg (other models)
MHC-GZR88D: Approx. 13.2 kg

Design and specifications are subject to change without notice.

SAFETY-RELATED COMPONET WARNING!

COMPONENTS IDENTIFIED BY MARK A OR DO'I'I'ED LINE
WITH MARK A ON THE SCHEMATIC DIAGRAMS AND IN

THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.

REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS

MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
