Sony hcd grx 40av rxd6av

Page 1

2 CD DIGITAL OUT (Square optical connector jack, rear panel) Wavelength 600 nm Output Level Ð18 dBm Tape player sectionRecording system 4-track 2-channel stereo Frequency response 60 - 13,000 Hz (±3 dB), (DOLBY NR OFF) using Sony TYPE I cassette Tuner sectionFM stereo, FM/AM superheterodyne tuner FM tuner sectionTuning range 87.5 - 108.0 MHz Antenna FM lead antenna Antenna terminals 75 W unbalanced Intermediate frequency 10.7 MHz AM tuner sectionTuning range 531 - 1,602 kHz (with the interval set at 9 kHz) 530 - 1,710 kHz (with the interval set at 10 kHz) Antenna AM loop antenna Antenna terminals External antenna terminal Intermediate frequency 450 kHz GeneralPower requirements European model: 230 V AC, 50/60 Hz Australian and South African models: 240 V AC, 50/60 Hz Mexican model: 120 V AC, 50/60 Hz Power consumption 190 W Dimensions (w/h/d) Approx. 280 ´ 340 ´ 390 mm (11 1/8 ´ 13 1/2 ´ 15 3/8 in.) Mass: Approx. 9.2 kg(20 lb 5 oz.) Design and specifications are subject to change without notice. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
