Ð 2 Ð MODEL IDENTIFICATION Ð BACK PANEL Ð MODEL PARTS NO. GR8 : EA3 model 4-986-845-1¹ GR8 : MY model 4-986-845-2¹ GR8 : E3, IA models 4-988-021-0¹ GR8 : E2 model 4-988-021-1¹ GR8 : SP model 4-988-021-2¹ GR8 : TW, JE models 4-988-021-3¹ GR8 : HK model 4-988-021-4¹ GR8 : AUS model 4-988-021-5¹ GR8 : MX model 4-988-021-6¹ GR8 : EA4, TH, SAF models 4-988-021-7¹ RX90 : AEP model (Made in Malaysia) 4-986-845-0¹ RX90 : AEP (Made in Indonesia), AED, G, UK models4-986-982-0¹ RX90 : EE, CIS model 4-986-982-1¹ ¥ Abbreviation AED : Northern European AUS : Australian E2 : 120 V AC Area in E model E3 : 240 V AC Area in E model EA3 : Saudi Arabia EA4 : Israeli EE : East European G : German HK : Hong Kong IA : Indonesia JE : Tourist MX : Mexican MY : Malaysia SAF : South African SP : Singapore TH : Thailand TW : Taiwan PARTS No. Tuner section FM stereo, FM/AM superheterodyne tuner FM tuner section Tuning range EE and CIS models: 65.0 Ð 74.0 MHz 87.5 Ð 108.0 MHz Other models: 87.5 Ð 108.0 MHz Aerial FM lead aerial Aerial terminals 75 ohm unbalanced Intermediate frequency 10.7 MHz UKV tuner section (EE and CIS models) Tuning range 65.0 Ð 74.0 MHz Polar stereo AM tuner section Tuning range RX90: MW: 531 Ð 1,602 kHz (with interval set at 9kHz) LW: 153 Ð 279 kHz (with interval set at 3kHz) MX, AUS, EA4 and TH models: 531 Ð 1,602 kHz (with the AM tuning interval st at 9 kHz) 530 Ð 1,710 kHz (with the AM tuning interval set at 10 kHz) Other models MW: 531 Ð 1,602 kHz (With the MW tuning interval set at 9 kHz) 530 Ð 1,710 kHz (With the MW tuning interval set 10 kHz) SW: 5.95 Ð 17.9 MHz (with the SW tuning interval set at 5 kHz) Aerial AM loop aerial Aerial terminals External aerial terminal Intermediate frequency 450 kHz General Power requirements RX90: 220 Ð 230 V AC, 50/60 Hz MX model: 120 V AC, 50/60 Hz MY and AUS models: 220 Ð 240 V AC, 50/60 Hz TH model: 220 V AC, 50 Hz Other models: 110 Ð 120 V or 220 Ð 240 V AC, 50/60 Hz Adjustable with voltage selector Power consumption RX90: 230 watts GR8: 220 watts Mass: Approx. 9.5 kg Supplied accessories: AM loop aerial (1) Remote RM-SD80 (1) Sony SUM-3 (NS) Batteries (2) FM lead aerial (1) Speaker cords (4) Design and specifications are subject to change without notice.
Page 2
Ð 3 Ð CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK ! OR DOTTED LINE WITH MARK ! ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB- LISHED BY SONY. This appliance is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT MARKING is located on the rear exterior. Laser component in this product is capable of emitting radiation exceeding the limit for Class 1. The following caution label is located inside the unit.
