HCD-GNZ333D/GNZ444D

Tuner section
FM stereo, FM/AM superheterodyne tuner

FM tuner section
Tuning range:
87.5 - 108.0 MHz (50 kHz step)
Antenna
FM lead antenna
Antenna terminals
75 Q unbalanced
Intermediate frequency
10.7 MHz

AM tuner section
Tuning range:
Saudi Arabian and Russian models:
531 - 1,602 kHz (with the interval set
at 9 kHz)
Other models:
531 - 1,602 kHz (with the interval set
at 9 kHz)
530 - 1,610 kHz (with the interval set
at 10 kHz)
Antenna
AM loop antenna
Antenna terminals
External antenna terminal
Intermediate frequency
450 kHz

General

Power requirements:
Russian model:
AC 220 - 240 V, 50/60 Hz
Saudi Arabian model:
AC 120 - 127, 220 - 240 V,
50/60 HZ, adjustable with voltage
selector
Other models:
AC 120, 220 or 230 - 240 V,
50/60 HZ, adjustable with Voltage
selector

Design and specifications are Subject to
change without notice.

U.S. and foreign [1]me Iirenxcdfmm
Dolby Laboratoriex.

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BY MARK A 0R DOTTED LINE
WITH MARK A ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
