H C D-EX6602/EX88OZIEX9902

AM tuner section
Tuning range
Latin American models:
530 kHz .. 1,710 kHz(10 kHz step)
531 kHz » 1,710 kHz (9 kHz step)
Russian models:
531 kHz »- 1,602 kHz (9 kHz step)
Other models:
531 kHz » 1,602 kHz (9 kHz step)
530 kHz - 1,610 kHz (10 kHz step)

General
Power requirements
Mexican model:
AC 120V 7 240V, 60 Hz
Other models:
AC 120 V - 240 V, 50/60 Hz
Power consumption
MHC-EX990: 115 W
MHC-EXSRO: 85 W
MHC»EX660: 65 W
Dimensions (w/h/d) (excl. speakers)
(Approx)
MHC-EX990/EX880: 240 mm X
315 mm X 382 mm
MHC-EX660: 240 mm X 315 mm X
347.8 mm
Mass (excl. speakers) (Approx)
MHC»EX990: 4.25 kg
MHC-EXSSO: 4.18 kg
MHC-EX660: 3.40 kg
Quantity ofthe main unit: 1 piece

Supplied accessories: Remote control (1),
R6 (Size AA) batteries (2), FM lead/
AM loop antenna (1)

Design and specifications are subject to
change without notice.

Standby power consumption: 0.5 W

NOTES ON CHIP COMPONENT REPLACEMENT

- Never reuse a disconnected chip component.

- Notice that the minus side ofa tantalum capacitor may be dam-
aged by heat.

FLEXIBLE CIRCUIT BOARD REPAIRING

- Keep the temperature of soldering iron around 270 °C during
repairing.

- Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).

- Be careful not to apply force on the conductor when soldering
or unsoldering.

CAUTION

Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radia-
tion exposure.

This appliance is classified as
a CLASS 1 LASER product.
KLASS LASERAPPARAT This marking is located on the
rear exterior.

CLASS 1 LASER PRODUCT
LUOKAN 1 LASEFlLAlTE

SAFETY-RELATED COMPONENT WARNING!

COMPONENTS IDENTIFIED BY MARK A OR DO'I'I'ED LINE
WITH MARK A ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
