Page 2

HCD-DZ370/DZ560IDZ570/DZ660/DZ777

Ver. 1.1

Sampllng frequencies

MP3 (MPEG 1 Audio Layers):

WMA:
AAC:

.4: (USB) port:
Max uniim Current:

Tuner Section
System

FM tuner section
Tlinlng range
North American models:

Other models.

Antenna (aerial)
Antenna (aerial) terminals
Intermediate frequency
AM tuner section

Tuning range

North American, Mexican,

32/44. [/48 kHz
44.1 kHz
44.1 kHz
500 mA

ILL quarIzVIncked digital
synthesizer

87.5 MHZr [080 MHZ

(100 kHz step)
37.5 MHZ , [08.0 MHz (50
kHz step)

FM ere antenna (aerial)
75 ohms, unbalanced
10.7 MHz

and Latin American
models:

530 kHz , 1,710 kHz (with
the interval set at 10 kHz)
531 kHz , 1,7|0 kl-IZ (\VItIi
the interval set at 9 kHz)

European. Russian, and Middle Eastern models:

531 kHz , 1,602 kHz (with
the interval set at 9 kHz)

Australian and New Zealand models:

Other models.

Antenna (aerial)
Intermediate frequency

531 kHz , 1,710 kl-IZ (\Vllh
the interval set at 9 kHz)
530 kHz , 1,710 kl-IZ (with
the interval set at 10 kHz)
531 kHz , 1,602 kHz (with
the interval set at 9 kHz)
530 kHz , 1,6 |0 kl-IZ (\VItIi
the interval set at 10 kHz)
AM loop antenna (aerial)
450 kHz

Video Section (DZ370ID2570IDZ777)

Outputs

VIDEO: I Vp»p 75 ohms
COMPONENT:

Y: l Vprp 75 ohms
IE'CB, IR/CR: 0.7 Vprp
75 ohms

HDMI OUT. Type A (19
Pm)

Video Section (DZ560IDZ660)

Outputs

Ge neraI

Power requirements
Mexican models:
Taiwan models:

Latin American models:
Other models.

Power consumption

VIDEO: I van 75 ohuis
RG/B: 0.7 Vprp 75 ohms
HDMI OUT. Type A (19
Pm)

120 V AC, 60 HZ

120 V AC, 50/60 HZ

110 V , 240VAC. 50/60 HZ
220 V , 240 VAC. 5060 Hz
On: 170 W

Standby: 0.3 W (at the
Power Saving mode)

Output voltage (DIGITAL MEDIA PORT)

DCSV

Output current (DIGITAL MEDIA PORT)

Imensions (approx. )

Mass (approx)

700 mA
430 mm x 66 mm x 385 mm
(w/h/d) incl. projecting parts
4.2 kg

Design and Specifications are Subject to change

without notice.

MODEL IDENTIFICATION

- Back Panel -
' o w L a
no Q] g] GEE ioodgg] oe 21L
Pans No.
Model Part No.

D2370: E12 model 3-273-759-9D
D2560: UK model 3-273-761-0D
D2660: AEP, UK model 3-273-761-1fl
D2777: E3 model 3-273-761-3D
D2777: AUS model 3-273-761-4D
D2777: KR model 3-273-761-6D
D2777: E15 model 3-273-761-9D
D2570: E12 model 3-273-762-0D
D2570: E3 model 3-273-762-11]
D2570: MX model 3-273-762-2D
D2570: AUS model 3-273-762-31]
D2570: KR model 3-273-762-6D
D2570: E32 model 3-273-762-7EI
D2570: TW model 3-273-762-81]
D2570: E15 model 3-273-762-9EI
D2570: PX model 3-875»160-1[|

Abbreviation
AUS :Australian model
E3 : 240 VAC Area in E model

E12 :220-240 VAC area in E model
E15 : Iran model

E32 : 110 - 240V AC area in E model
KR : Korean model

MX Mexican model

TW : Taiwan model

Special Component Notice

The components identified by mark [El contain confidential infor-
mation.

Strictly follow the instructions whenever the components are re-
paired and/or replaced.

SAFETY-RELATED COMPONET WARNING!

COMPONENTS IDENTIFIED BY MARKAOR DO'I'I'ED LINE
WITH MARKAON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
