Page 2

HCD-D2260/ D2270/ HD2278
Ver. 1.2

AM tuner section
Tuning tange
North American. Mexican, and Latin American models:
530 kHz , 1.710 kHz (With
the interval Set at 10 kHz)
531kl-lz 71.710 kHz(w1Ih
the interval set at 9 kHz)
European, Russian. and Middle Eastern models:
531 kHz , 1.602 kHz (With
the interval set at 9 kHz)
Australian and New Zealand models:
531 kHz , 1.710 kHz(\v1Ih
the interval set at 9 kHz)
530 kHz , 1.710 kHz (W1th
the interval set at 10 kHz)
531 kHz , 1.602 kHz (With
the interval Set at 9 kHz)
530 kHz , 1.610 kHz(w1Ih
the interval set at 10 kHz)
AM loop antetma (aerial)

OtIIeI' nlodels

Antenna (aettal)

Intermediate frequency 450 kHz
Video Section (DZ260)
Outputs R/G/B: 0.7 Vprp 75 ohms

I-IDMI OUT: Type A ( [9 pin)

Video Section (D2270/HD2278)
Outputs VIDEO: 1 Vprp 75 ohms
COMPONENT:
Y: 1 Vprp 75 ohms
IB/CB. PR/CR: 0.7 Vprp
75 ohms
I-IDMI OUT: Type A (19 pin)

General

Power requirements
Notth American models:
Mexican models:
Venezuelan models:
Taiwan models:
Argentine models:
Latin American models:
Othet- nlodels

Power consumption

120 V AC. 60 HZ

120 V AC. 60 HZ

120 V AC. 60 HZ

120 V AC. 50/60 HZ

220 V , 240 V AC, 50/60 Hz
110 V , 240 V AC, 50/60 HZ
220 V , 240 V AC. 50/60 Hz

HDZ278: On: 155 w
Standby: 0.3 w (at the
Power Saving mode)

Dzzn0/Dz27o: On: 160W

Standby: 0.3 w (at the
Power Saving mode)

Output yoltage (DIGITAL MEDIA PORT)

(DZZoO/HDZNS only) DC 5 v

Output Curlenl (DIGITAL MEDIA PORT)

(DZ360/HDZ27R only) 700 mA

Dimensions (approx) 430 111111 x no mm X 385 mm
(17 in x 25/1; in x 15 1/4 in)
(w/h/d) incl. ptojectmg parts

Mass (approx) 4.2 kg (9 lb 5 01)

Design and specifications are subject to change without
notice.

SAFETY-RELATED COMPONET WARNING!

COMPONENTS IDENTIFIED BY MARKAOR DOTTED LINE
WITH MARKAON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL T0 SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.

ATTENTION AU COMPOSANT AYANT RAPPORT
A LA SECURITE!

LES COMPOSANTS lDENTlFlEs PAR UNE MARQUE ASUFI
LES mAGRAMMES SCHEMAnOUES ET LA LSTE DES
PIECES SONT CRITIQUES POUR LA sEcuanE DE FONC-
n0NNEMENt NE REMPLACER CES COM-POSANTS oUE
PAR DES HECES SONY DONT LES NUMEROS SONT DON-
NES DANS CE MANUEL ou DANS LES SUPPLEMENTS
PUBLIES PAR SONY.

2

MODEL IDENTIFICATION
- Back Panel -

Doom
CEF:

Parts No.
Model Part No.
D2260: AEP, UK models 3-273-759-0D
HD2278: US model 3-273-759-1D
HD2278: CND model 3-273-759-2U
D2270: TW model 3-273-759-BD
D2270: E3 model 3-273-760-0D
D2270: E32 model 3-273-760-1 D
D2270: MX model 3-273-760-2D
D2270: E12 model 3-273-760-4D
D2270: AUS model 3-273-760-51]
D2270: AR model 3-273-760-6311
D2270: KR model 3-273-760-81]
D2270: E87 model 3-875-160-2I]

Abbreviation

AR : Argentina model

AUS :Australian model

CND : Canadian model

E3 : 240 V AC area in E model
E12 :220-240 V AC area in E model
E32 : 110-240 VAC area in E model
E87 : Venezuelan model

KR : Korea model

MX : Mexican model

TW : Taiwan model

Special Component Notice

The components identified by mark [31 contain confidential infure
mation.

Strictly follow the instructions whenever the components are re
paired and/or replaced.

Notice pour composants spéciaux

Les composunts identifies par la marque IE! Contiennent des infor-
mations confidentialles.

Suivre scrupuleusement les instructions chaque fois quun com-
posant est remplacé et / ou reparé.
