HCD-DX400
Ver. 1.4

General

Power requlrements

Chllean and Peruvian models:

I IO V 7120 V/ZZO V r 240 V AC. 50/60HZ
120 V AC. 60 HZ

120 V AC. 50160 Hz

220 V r 240 V V, 60 HZ

220 V r 240 VAC, 5060 HZ

Mexican model:
Talwan model:
Korean model:
Other models:
Power consumption:
On: 25 Watts
Standby: 0.5 Watts
Dllnenslons (w/h d) (excl, speakers):

Approx. 175 x 240 x 210 mm
Mass (excl, speakers): 2.4 kg

Design and Specificallons are Subjecl to change without notice.

~ This system Incorporates Dolby Dlgltal.

' Manufactured under license from Dolby Laboratories. Dolby and the dDHbIevD
symbol are trademarks of Dolby Laboratories.

~ MPEG Layer-3 alldlo codlng technology and patents licensed from Fraurtltoter lls
and Thomson,

- DIVX. Dle Certified and assoclated logos are reglslered trademarks otDle.

Inc. DivX grants licensees the right to use the Dle trademark.

ABOUT DIVX VIDEO: Dle" Is a dlgltal video format created by DIVX, Inc.

This Is an ofliclal DIVX Certified devlce that plays DIVX video.

Vlstt wwwdlvxcoln for lnore information and sottware tools to convert your files

Into Dle vldeo.

ABOUT DIVX VIDEOrONrDEMAND This Dle Certifiedt device must be

reglstered in order to play Dle video-on-Delnand (VOD) content. To generate

the registration code. locate the Dle VOD section In the device setup menu. Go

to vod.dlvx.corn With this code to complete the registration process and learn more

about DlVX VOD,

Wlndows Media |S a registered trademark otMtcrosot't Corporation m the United

States and/or other countries.

THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT

PORTFOLIO LICENSE FOR THE PERSONAL AND NONCOMMERCIAL USE

OF A CONSUMER FOR

(l) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG4 VISUAL

STANDARD (MPEG4 VIDEO")

AND/OR

(II) DECODING MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER

ENGAGED IN A PERSONAL AND NONrCOMMERCIAL ACTIVITY ANDIOR

WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO

PROVIDE MPEG-4 VIDEO.

NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER

USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO

PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING

MAY BE OBTAINED FROM MPEG LA, LLC.

SEE http://www.inpeglacom/

NOTES ON CHIP COMPONENT REPLACEMENT

- Never reuse a disconnected chip component.

- Notice that the minus side ofa tantalum capacitor may be dam-
aged by heat.

FLEXIBLE CIRCUIT BOARD REPAIRING

- Keep the temperature of soldering iron around 270 °C during
repairing.

- Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).

- Be careful not to apply force on the conductor when soldering
or unsoldering.

CAUTION

Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radia-
tion exposure.

This appliance is classified as
a CLASS 1 LASER product.
This marking is located on the
rear exterior.

CLASSI LASER PRODUCT
LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

TABLE OF CONTENTS

1. SERVICING NOTES. 3
2. DISASSEMBLY

2-1. Disassembly Flow ........... 6
2-2. Cover (Top).. 6
2-3. Front Panel Block 7
2-4. Knob (Volume) . 7

2-5. DVD Block ..... 8

2-6. MAINBoard... 9
2-7. FFCHolder.. ........ 9
2-8. Optical Pick-up Block (KHM-313CAA). 9
2-9. Belt ............... 9

3. DIAGRAMS

3-1. Block Diagram ........
3-2. Printed Wiring Board - MAIN Board
3-3. Schematic Diagram - MAIN Board (1/2) -...
3-4. Schematic Diagram - MAIN Board (2/2) -...
3-5. Printed Wiring Board - CONTROL Board -.
3-6. Schematic Diagram - CONTROL Board -.

4. EXPLODED VIEWS
4-1. Cover Section.

4-2. Front Panel Section.
4-3. MAIN Board Section.
4-4. DVD Mechanism Deck Section ....................

SAFETY-RELATED COMPONENT WARNING!

COMPONENTS IDENTIFIED BY MARK A OR DO'I'I'ED LINE
WITH MARK A ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
