HCD-BX5BT/CBX1/CBX3
Ver. 1.3

Laser Diode Properties
Emission duration: continuous
Laser Outpufi: Less than 44.511 w
* This output is the value measurement at a distance
of 200mm from the Objectlve lens surface on the
Optical Pickrup Block with 7mm aperture.
Frequency response: 20 Hz , 20 kHz
SignalrtOrnoIse ratio: More than 90 dB
Dynamic range: More than 90 dB

Tuner section
CBXS:
FM stereo. FM/AM superheterodyne tunei-

FM tuner Section:
Tuning range:
Canadian model:
875 7108.0 MHZ (100 kHz step)
Other models:
875 7108.0 MHZ (50 kHz step)
Antenna: FM lead antenna
Antenna terminals: 75 OlllllS unbalanced
Intermediate frequency: 10.7 MHz
AM tuner section:
Tuning range:
Canadian model:
530 r 1.710 kHz (with 10 kHz tuning interval)
531 r 1.710 kHz (with 9 kHz tuning interval)
European model:
531 r 1.602 kHz (with 9 kHz tuning interval)
Other models:
530 r 1.710 kHz (with 10 kHz tuning interval)
531 r 1.602 kHz (with 9 kHz tuning interval)
Antenna: AM loop antenna external antenna terminal
Intermediate frequency: 450k1-Iz

BXSBT/CBXl :
FM stereo. FM/AM superheterodyne tuner

FM tuner Section:
TuIIIIIg range
87.5 7108.0 MHZ (100 kHz step)
Antenna: FM lead antenna
Antenna terminals: 75 ohms unbalanced
Intermediate frequency: 10.7 MHz
AM tuner section:
Tuning range
530 r 1.710 kHz (with 10 kHz tuning interval)
531 r 1.710 kHz (with 9 kHz tuning interval)
Anteniia: AM loop antenna, external antenna terminal
Intermediate frequency: 450 kHz

General

Power requirements:

120V AC, 60 HZ(BX5BTICBX1ICBX3: Canadian
model)

230V AC, 50/60 Hz (CBXS: European model)

230 r 240 V AC, 50/60 HZ (CBXS: Australian model)
220V AC. 60 Hz (CBX3: Korean model)

120V AC. 50/60 Hz (CBX3: Taiwan model)

120V. 220 V, 230 V r 240V AC, 50/60 HZ, adjustable
with voltage selector tcaxs» Other models)

Power consumption:

40 watts (BXSBT/CBXI)

65 watts (csxz)

Dimensions (w/h/d) (excl, speakers):

Approx, 200 X 132 X 298 min

Mass texcl, speakers):

3.5 kg (BXSBT)

3.4 kg (CBXl)

3.7 kg (CBX3)

Design and specifications are subject to change without
notice,

SAFETY-RELATED COMPONENT WARNING !!

COMPONENTS IDENTIFIED BY MARK A OR DOTTED LINE
WITH MARK A ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL T0 SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.

2

Notes on chip component replacement
0 Never reuse a disconnected chip component.
P Notice that the minus side of a tantalum capacitor may be
damaged by heat.

Flexible Circuit Board Repairing
P Keep the temperature of the soldering iron around 270 C
during repairing.
P Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
0 Be careful not to apply force on the conductor when soldering
or unsoldering.

CAUTION

Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radiation
exposure

This appliance is
classified as :1 CLASS

1 LASER product. This
marking is located on the
rear exterior.

cuss t LASER vacuum
LUOKAN t LASERLAlTE

KLASS t LASERAPPARAT

ATTENTION AU COMPOSANT AYANT RAPPORT
A LA SEOURITE!

LES COMPOSANTS lDENTIPlES PAR UNE MARQUE A SUR
LES DIAGRAMMES SOHEMATIOUES ET LA LISTE DES
PIECES SONT CRITIQUES POUR LA SECURITE DE
FONCTIONNEMENT. NE REMPLACEFI CES COM- POSANTS
OUE PAR DES PIECES SONY DONT LES NUMEROS SONT
DONNES DANS CE MANUEL OU DANS LES SUPPLEMENTS
PUBLIES PAR SONY.
