AEP Model
FH-41 4
Saudi Arabia Model
FH-414L
OFH-414 & FH-414L is composed of following models.
As for the service manual it is issued for each component
, model, than, please refer to it.
COMPONENT MODEL NAME FOR FH-414 & FH-414L
FH-4l4
FH»414L
WG model AEP model
TUNER, DECK,
AMPLIFIER HST'414 HST-414L
SPEAKER
SYSTEM 551 SS-H414
0 Items marked "t" are not stocked slnce
they are seldom required for routine
service. Some delay should be antlci-
pared when ordering these Items.
ACCESSORY & PACKING MATERIAL
Part No. Description
*X-4919-684-1 HANDLE ASSY
1601-34941 ANTENNA, LOOP
3-750v219-11 (AEP, Saudi Arabia) I I. MANUAL,
INSTRUCTION
3-750-219-41 (AEP) . . .MANUAL, INSTRUCTION
*4-930-360-01 (Saudi Arabiai . .l INDIVIDUAL
CARTON
Power requlrements
Power consumption
Dimensions
Weight
SPECIFICATIONS
AEP model:220V, 50/60Hz
Saudi Arabia model:
110-120V or 220 7240V AC adjustable,50/60Hz
65watts
Approx 595 x 270 x 250 mm (w/h/d)
(23l2 x 105/4 x 10 inches)
incl, projecting parts and controls
Approx. 9.5 kg (20 lb 15 oz) net
Design and specifications subject to change without notice
Sony Corporation
9953-674-11 Audio Group
COMPACT Hl-DENSITY
CflMPflNENT SYSTEM
SONY;
English
8980436-1
Printed in Japan
@1989}
