Sony ecm 360 service manual
This is the 6 pages manual for sony ecm 360 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony ecm 360 service manual (Ocr-read)
Page 1
Ð 2 Ð SECTION 1 GENERAL LOCATION AND FUNCTION OF CONTROLS This section is extracted from instruction manual.
Page 2
Ð 3 Ð SECTION 2 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 2-1. CASE ASSY, MICROPHONE 2-2. SWITCH BOARD r The equipment can be removed using the following procedure. Set Case ASSY, microphoneSwitch board Translation board (ECM-330 only) 5 Remove solder Frame Grip 3 Screw (+KTP 2x5) 42 1 Case ASSY, microphone Lead wire (Black) 5 Remove solder 5 Remove solder 3 Claws 1 Claw 6 Spring, ground 1 Claw WhiteWhite Black Cover (B) Black Black RedWhite (ECM-360 only) Black (ECM-360)/White (ECM-330) Switch board Orange Red 42 1 Claws Frame
