Sony dxa wz8d
This is the 28 pages manual for sony dxa wz8d.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from sony dxa wz8d (Ocr-read)
Page 1
2 DXA-WZ8D SAFETY-RELATED COMPONENT WARNING!! COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Notes on chip component replacement -Never reuse a disconnected chip component. -Notice that the minus side of a tantalum capacitor may be damaged by heat. Flexible Circuit Board Repairing -Keep the temperature of soldering iron around 270˚C during repairing. -Do not touch the soldering iron on the same conductor of the circuit board (within 3 times). -Be careful not to apply force on the conductor when soldering or unsoldering. TABLE OF CONTENTS 1. GENERAL ·········································································· 3 2. DISASSEMBLY························································· 5 2-1. Case ··············································································· 5 2-2. Switching Power, DC Fan and Back Panel ··················· 6 2-3. TC MAIN Board ··························································· 6 2-4. FRONT AMP Board and SURROUND AMP Board ···· 7 2-5. Front Panel Assy ···························································· 7 2-6. Tape Mechanism Deck (CWM43RR23) ······················· 8 2-7. Lid (TC) Assy, Holder (A) Assy and Holder (B) Assy ·· 8 3. ELECTRICAL ADJUSTMENTS ································· 9 4. DIAGRAMS ······································································ 10 4-1. Block Diagram ···························································· 11 4-2. Printed Wiring Board – TC MAIN Board – ··············· 12 4-3. Schematic Diagram – TC MAIN Board (1/2) – ······ 13 – TC MAIN Board (2/2) – ······ 14 4-4. Printed Wiring Board – FRONT AMP Board – ········· 15 4-5. Schematic Diagram – FRONT AMP Board – ········· 16 4-6. Printed Wiring Board – SURROUND AMP Board – 15 4-7. Schematic Diagram – SURROUND AMP Board – 16 5. EXPLODED VIEWS 5-1. Front Panel Section ····················································· 17 5-2. Chassis Section ···························································· 18 5-3. Tape Mechanism Deck Section ··································· 19 6. ELECTRICAL PARTS LIST ······································· 20 Unleaded solder Boards requiring use of unleaded solder are printed with the lead- free mark (LF) indicating the solder contains no lead. (Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK Unleaded solder has the following characteristics. -Unleaded solder melts at a temperature about 40°C higher than ordinary solder. Ordinary soldering irons can be used but the iron tip has to be applied to the solder joint for a slightly longer time. Soldering irons using a temperature regulator should be set to about 350°C. Caution: The printed pattern (copper foil) may peel away if the heated tip is applied for too long, so be careful! -Strong viscosity Unleaded solder is more viscous (sticky, less prone to flow) than ordinary solder so use caution not to let solder bridges occur such as on IC pins, etc. -Usable with ordinary solder It is best to use only unleaded solder but unleaded solder may also be added to ordinary solder. [When bringing in the equipment for service] In case of repairing, please bring the entire system set([HCD-WZ5, DXA-WZ5],except for the speaker) to the service station. Other models: 120 V, 220 V or 230 – 240 V AC, 50/60 Hz Adjustable with voltage selector Power consumption European and Russian models: 235 watts 0.3 watts (in Power Saving Mode) Other models: 260 watts Dimensions (w/h/d) Amplifier/Tape deck: Approx. 255 ×135 × 330 mm Mass Amplifier/Tape deck: Approx. 8.5 kg Supplied accessories: Remote Commander (1) Batteries (2) AM loop antenna (1) FM lead antenna (1) Speaker pads (20) Speaker cords (5) Video cord (1) Design and specifications are subject to change without notice. MODEL IDENTIFICATION - BACK PANEL - -Abbreviation AUS: Australian model E2 : 120V AC area in E model E3 : 240V AC area in E model E15 : 220-240V AC area in E model EA : Saudi Arabia model KR : Korean model PA RTS No. VOLTAGE SELECTOR Switch MY : Malaysia model PH : Philippines model RU: Russian model SP : Singapore model TH : Thai model MODEL AEP, UK models EA model E2,E3,E15 models AUS model TH model PA RTS No. 4-244-898-0s 4-244-898-1s 4-244-898-2s 4-244-898-4s 4-244-898-6s MODEL KR model MY,SP models RU model PH model PA RTS No. 4-244-898-7s 4-244-898-8s 4-244-898-9s 4-247-937-0s
Page 2
3 DXA-WZ8D This section is extracted from instruction manual. SECTION 1 GENERAL Main unit Deck A wl Deck B wh A Z (eject) wk (39) Z B (eject) wj (39) ALPHABETICAL ORDER A – L BUTTON DESCRIPTIONS Amplifier/Tape deck
