– 3 – - DIFFERENT PARTS LIST DVP-S535D: AEP, UK DVP-S536D: AEP, UK Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 8-1. EXPLODED VIEWS - The mechanical parts with no reference number in the exploded views are not supplied. - Accessories and packing materials are given in the last of the electrical parts list. NOTE: - -XX and -X mean standardized parts, so they may have some difference from the original one. - Items marked * are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. - Color Indication of Appearance Parts Example: KNOB, BALANCE (WHITE) . . . (RED) ↑↑ Parts Color Cabinet's Color- Description about destination (AEP model) AEP 09 This number indicates the suffix number of its model code.R 8-1-1. CASE ASSEMBLY (See Service Manual Page 8-1.) - : Points changed parts. - = - - 1 X-3950-731-1 PANEL ASSY, FRONT 3 4-217-485-01 EMBLEM (5-A), SONY 4 3-975-726-61 EMBLEM, DVD 5 3-061-719-41 COVER, TRAY 6 3-059-322-41 STICK, CURSOR 10 3-710-901-61 SCREW, TAPPING 11 3-062-941-21 CASE 1011 10 5 4 10 9 3 7 8 6 not supplied 1 2 -== = = 1 X-3950-412-1 PANEL ASSY, FRONT 3 4-963-404-21 EMBLEM (5-A), SONY 4 3-975-726-71 EMBLEM, DVD 5 3-059-377-01 COVER, TRAY 6 3-059-322-31 STICK, CURSOR 10 3-710-901-11 SCREW, TAPPING not suppliedhttp://cxema.ru
